AUDIO SETTINGS
2-way crossover setting items
SPK SIZE
FRONT SIZE
3.5" / 4" / 4.75" / 5" / 6.5" / 6.75" / 7" / 4×6" / 5×7" /
6×8"
/ 6×9" / 7×10"
TWEETER
SML / MID / LRG / NONE (not connected)
REAR
*
1
3.5" / 4" / 4.75" / 5" / 6.5" / 6.75" / 7" / 4×6" / 5×7" / 6×8" / 6×9" /
7×10"
/ NONE (not connected)
SUBWOOFER
*
2
*
3
6.5" / 8" / 10" / 12" / 15" OVER / NONE (not connected)
X ' OVER
TWEETER FRQ
1KHZ / 1.6KHZ / 2.5KHZ / 4KHZ / 5KHZ / 6.3KHZ / 8KHZ /
10KHZ / 12.5KHZ
GAIN LEFT
–08DB to 00DB
GAIN RIGHT
–08DB to 00DB
FRONT HPF FRQ
30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ / 100HZ /
120HZ
/ 150HZ / 180HZ / 220HZ / 250HZ / THROUGH
SLOPE
–06DB / –12DB / –18DB / –24DB
GAIN
–08DB to 00DB
REAR HPF
*
1
FRQ 30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ / 100HZ /
120HZ
/ 150HZ / 180HZ / 220HZ / 250HZ / THROUGH
SLOPE
–06DB / –12DB / –18DB / –24DB
GAIN
–08DB to 00DB
SUB.W LPF
*
2
*
3
FRQ 30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ / 100HZ /
120HZ
/ 150HZ / 180HZ / 220HZ / 250HZ / THROUGH
SLOPE
–06DB / –12DB / –18DB / –24DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –08DB to 00DB
3-way crossover setting items
SPK SIZE
TWEETER
SML/ MID/ LRG
MID RANGE
3.5" / 4" / 4.75" / 5" / 6.5" / 6.75" / 7" / 4×6" / 5×7" / 6×8" / 6×9"
WOOFER
*
3
6.5" / 8" / 10" / 12" / 15" OVER / NONE (not connected)
X ' OVER
TWEETER HPF FRQ
1KHZ / 1.6KHZ / 2.5KHZ / 4KHZ / 5KHZ / 6.3KHZ / 8KHZ /
10KHZ / 12.5KHZ
SLOPE
–06DB / –12DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –08DB to 00DB
MID RANGE HPF FRQ
30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ / 100HZ /
120HZ
/ 150HZ / 180HZ / 220HZ / 250HZ / THROUGH
HPF SLOPE
–06DB / –12DB
LPF FRQ
1KHZ / 1.6KHZ / 2.5KHZ / 4KHZ / 5KHZ / 6.3KHZ / 8KHZ /
10KHZ / 12.5KHZ / THROUGH
LPF SLOPE
–06DB / –12DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –08DB to 00DB
WOOFER
*
3
LPF FRQ 30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ / 100HZ /
120HZ
/ 150HZ / 180HZ / 220HZ / 250HZ / THROUGH
SLOPE
–06DB / –12DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –08DB to 00DB
*
1
Displayed only when [ SPK/PRE  OUT ] is set to [ REAR/REAR ] or [ REAR/SUB.W ]. (  21,
22
)
*
2
For KD-X330BTS: Displayed only when [ SPK/PRE  OUT ] is set to [ REAR/SUB.W ] or
[
SUB.W/SUB.W ]. (  21, 22 )
*
3
Displayed only when [ SUB.W ] is set to [ ON ]. (  21 )
