Signal control board
Block No. [0][2]
R622 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R625 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R626 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R901 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R902 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R903 NRS181J-0R0X MG RESISTOR 0
Ω
1/8W J
VR101 QVP0033-501Z TRIM RESISTOR 500
Ω
VR201 QVP0033-501Z TRIM RESISTOR 500
Ω
L1 QQR1664-001 CHORK COIL
L2 QQR1277-001Z COIL
L3 QQR1277-001Z COIL
L5 QQR1277-001Z COIL
L6 QQR1277-001Z COIL
L7 QQR1277-001Z COIL
L101 QQLZ003-1R0 COIL 1uH
L201 QQLZ003-1R0 COIL 1uH
T1 QQS0354-001 SW TRANSF
BK1 LV36137-001A CON-BRACKET
CN1 QNB0277-001 SCREW TERMINAL
CN2 QGA2001F1-03 CONNECTOR W-B (1-3)
CN101 QNB0278-001 SCREW TERMINAL
CN504 QGA2001C1-10 CONNECTOR W-B (1-10)
CN505 QGA2001C1-10 CONNECTOR W-B (1-10)
CN591 QGA2001F1-03 CONNECTOR W-B (1-3)
CN901 QGA4201F1-04 CONNECTOR W-B (1-4)
EP101 QNZ0136-001Z EARTH PLATE
F1 QNG0059-001 FUSE HOLDER
F2 QNG0059-001 FUSE HOLDER
F3 ICP-S1.2-X IC PROTECTOR 1.2A
F4 ICP-S1.2-X IC PROTECTOR 1.2A
F5 ICP-S1.2-X IC PROTECTOR 1.2A
J501 QNN0745-001 PIN JACK
TH1 QAD0070-222 P THERMISTOR 120Åé 2.2k
Ω
16V
TH2 QAD0070-222 P THERMISTOR 120Åé 2.2k
Ω
16V
TH3 NAD0041-471X POSISTOR 470
Ω
W301 QZW0010-001 STYLE PIN
Symbol No.
Part No. Part Name Description Local
IC531 NJM4580V-X IC
IC532 NJM4580V-X IC
IC533 NJM4580V-X IC
IC561 NJM4580V-X IC
IC562 NJM4580V-X IC
IC563 NJM4580V-X IC
D1921 SLR343BBT-T LED
D1922 SLR343BBT-T LED
C1531 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1532 QFV61HJ-563Z MF CAPACITOR 0.056uF 50V J
C1533 QFV61HJ-563Z MF CAPACITOR 0.056uF 50V J
C1534 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1535 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1536 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1537 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C1538 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C1561 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1562 NDC31HJ-180X C CAPACITOR 18pF 50V J
C1563 QFV61HJ-224Z MF CAPACITOR 0.22uF 50V J
C1564 QFV61HJ-183Z MF CAPACITOR 0.018uF 50V J
C1565 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C1566 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C1567 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1631 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1632 QFV61HJ-563Z MF CAPACITOR 0.056uF 50V J
C1633 QFV61HJ-563Z MF CAPACITOR 0.056uF 50V J
C1634 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1635 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
Symbol No.
Part No. Part Name Description Local
C1636 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1661 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1662 NDC31HJ-270X C CAPACITOR 27pF 50V J
C1663 QFV61HJ-224Z MF CAPACITOR 0.22uF 50V J
C1664 QFV61HJ-183Z MF CAPACITOR 0.018uF 50V J
C1667 NDC31HJ-470X C CAPACITOR 47pF 50V J
R1531 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1532 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1533 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1534 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R1535 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1536 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R1537 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1538 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1539 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1540 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R1561 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1562 NRSA63J-112X MG RESISTOR 1.1k
Ω
1/16W J
R1563 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R1564 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1565 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R1566 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1567 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1568 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R1569 NRSA63J-564X MG RESISTOR 560k
Ω
1/16W J
R1570 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1571 NRSA63J-203X MG RESISTOR 20k
Ω
1/16W J
R1572 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1631 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1632 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1633 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1634 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R1635 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R1636 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R1637 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1638 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1639 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1640 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R1661 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1662 NRSA63J-112X MG RESISTOR 1.1k
Ω
1/16W J
R1663 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R1664 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R1665 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R1666 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1667 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1668 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R1669 NRSA63J-564X MG RESISTOR 560k
Ω
1/16W J
R1670 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R1671 NRSA63J-203X MG RESISTOR 20k
Ω
1/16W J
R1672 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R1921 NRS125J-471X MG RESISTOR 470
Ω
1/2W J
VR531 QVQ0339-C54 V RESISTOR
VR561 QVQ0338-B24 V RESISTOR
VR562 QVQ0338-B24 V RESISTOR
S1531 QSW1151-001 SLIDE SWITCH
