KS-AX6700
3-3
Item Parts number Parts name AreaQ'ty Description
1 MAHS070047-2 HEAT SINK 1
2 MAFP076019-1 FRONT PANEL 1
3 MARP706021-1 REAR PANEL 1
4 MABC076014-1 BOTTOM COVER 1
5 MATC041489-1 CONTROL PANEL 1
6 MASO051491-1 CCFL COVER 1
7 MABR031494-0 TR BRACKET
(
A
)
2
8 MABR031493-0 TR BRACKET
(
B
)
1
9 MABR031495-0 TR BRACKET
(
C
)
1
10 MOCU011504-2 TR BRACKET CUS 4
11 MOCU011503-2 TR BRACKET CUS 2
12 MOCU011505-2 TR BRACKET CUS 2
13 MASP001519-0 SILICON PAD
(
A
)
2
14 MASP001509-0 SILICON PAD
(
B
)
1
15 MASP001520-0 SILICON PAD
(
C
)
1
16 MAPO022903-0 PIPE 1
17 MATC036022-1 TOP PLATE 1
18 MAIL001501-1 ILLUMINATOR 1
19 MOKB076023-1 VOLUME KNOB 3
20 MOKB076024-1 SWITCH KNOB 1
21 MOWA051506-0 POLY WASHER 2
22 MABU031496-0 WIRE BUSHING 1
23 MOCU111508-0 INSULATION SHEE 1
24 MOCU111535-1 INSULATION SHEE 1
25 MOFI011538-0 FIBER PLATE 1
26 MOCU011511-1 CCFL CUSHION
(
A
)
1
27 MOCU011512-0 CCFL CUSHION
(
B
)
2
28 MOCU001521-0 RUBBER CUSHION 1
29 MOCU014097-0 RUBBER CUSHION 1
30 MOCU014097-0 RUBBER CUSHION 2
31 MOCU021701-0 FIBER CUSHI 3
33 MOCU061498-0 EVA CUSHION 2
34 MNSC00140-9.3 SCREW 2
36 MNSC00740-14 SCREW 13
37 MBSC03230-08 SCREW 6
38 MBSC00230-06 SCREW 14
39 MNSC00630-06 SCREW 8
40 MBSC04330-05 SCREW 4
41 MBSC00330-08 SCREW 6
A
Parts list ( Enclosure assembly
)
Block No. M1MM
