JVC KS-FX460R User Manual

3-12
KS-FX460R/KS-FX463R
Item
Parts number Parts name Area
Electrical parts list(Main board)
Remarks
Block No. 01
A
R 726 NRS181J-472X MG RESISTOR
R 727 NRSA02J-472X MG RESISTOR
R 733 NRS181J-472X MG RESISTOR
R 734 NRSA02J-472X MG RESISTOR
R 736 NRSA02J-103X MG RESISTOR
R 737 NRSA02J-473X MG RESISTOR
R 738 NRSA02J-473X MG RESISTOR
R 740 NRSA02J-473X MG RESISTOR
R 743 NRSA02J-103X MG RESISTOR S
Q
USE
R 746 NRSA02J-473X MG RESISTOR
R 748 NRSA02J-473X MG RESISTOR INTI. RES.
R 750 NRSA02J-473X MG RESISTOR INTI. RES.
R 751 NRSA02J-104X MG RESISTOR
R 752 NRSA02J-334X MG RESISTOR
R 753 NRSA02J-223X MG RESISTOR
R 754 NRSA02J-101X MG RESISTOR
R 755 NRSA02J-103X MG RESISTOR
R 756 NRSA02J-104X MG RESISTOR
R 757 NRSA02J-104X MG RESISTOR
R 758 NRSA02J-101X MG RESISTOR
R 759 NRSA02J-334X MG RESISTOR
R 761 NRSA02J-222X MG RESISTOR
R 762 NRSA02J-222X MG RESISTOR
R 763 NRSA02J-222X MG RESISTOR
R 773 NRSA02J-473X MG RESISTOR
R 901 QRE141J-121Y C RESISTOR 120 5% 1/4W
R 911 NRSA02J-271X MG RESISTOR
R 912 NRSA02J-271X MG RESISTOR
R 913 NRS181J-100X MG RESISTOR
R 941 NRSA02J-473X MG RESISTOR
R 959 NRSA02J-222X MG RESISTOR
R 960 NRSA02J-273X MG RESISTOR
R 961 QRE141J-470Y C RESISTOR 47 5% 1/4W
R 962 NRSA02J-682X MG RESISTOR
R 963 NRS181J-123X MG RESISTOR
R 966 NRSA02J-473X MG RESISTOR
R 967 NRSA02J-222X MG RESISTOR
R 969 NRS181J-222X MG RESISTOR
R 970 NRS181J-473X MG RESISTOR
R 974 NRSA02J-123X MG RESISTOR
R 975 NRSA02J-243X MG RESISTOR
R 977 NRS181J-181X MG RESISTOR
R 978 NRSA02J-473X MG RESISTOR
R 979 NRSA02J-473X MG RESISTOR
R 980 NRSA02J-102X MG RESISTOR
TU 1 QAU0156-002 TUNER
X 701 QAX0406-002Z
X 761 QAX0263-001Z CRYSTAL
CRYSTAL
