3-11
KS-FX460R/KS-FX463R
Item
Parts number Parts name Area
Electrical parts list(Main board)
Remarks
Block No. 01
A
D 977 MA152WK-X SI DIODE
D 978 MTZJ11B-T2 ZENER DIODE
D 980 MA152WA-X DIODE
D 981 MA152WA-X DIODE
D 982 MA152WK-X SI DIODE
IC701 UPD178016AGC555
IC751 HD74HC126FP-X IC
IC761 SAA6579T-X IC
IC901 UPC1228HA IC
IC911 TEA6320T-X IC
IC941 HA13158A IC
IC961 AN80T05LF IC
J 1 QNZ0009-001 CAR ANT JACK
J 751 QNZ0095-001 CONNECTOR
J 931 QNN0183-001 PIN JACK
L 1 QQL231K-4R7Y INDUCTOR
L 701 QQL231K-470Y INDUCTOR
L 961 QQR0528-002 CHOKE COIL
Q
1 DTC114EKA-X TR
Q
2 DTC114EKA-X TR
Q
3 2SC2412K/R/-X TRANSISTOR
Q
4 DTA114EKA-X DIGITAL.TRANSIS
Q
5 2SA1037AK/RS/-X TRANSISTOR
Q
6 2SA1037AK/RS/-X TRANSISTOR
Q
7 2SC3661-X TRANSISTOR
Q
10 2SC3661-X TRANSISTOR
Q
11 2SC2412K/R/-X TRANSISTOR
Q
12 2SC2412K/R/-X TRANSISTOR
Q
131 2SC2412K/R/-X TRANSISTOR
Q
151 2SC2412K/R/-X TRANSISTOR
Q
231 2SC2412K/R/-X TRANSISTOR
Q
251 2SC2412K/R/-X TRANSISTOR
Q
301 2SD601A/R/-X TRANSISTOR S
Q
USE
Q
302 2SD601A/R/-X TRANSISTOR S
Q
USE
Q
701 2SC2412K/R/-X TRANSISTOR
Q
951 DTA114EKA-X DIGITAL.TRANSIS
Q
959 DTC114EKA-X TR
Q
960 2SA1037AK/RS/-X TRANSISTOR
Q
961 2SA1037AK/RS/-X TRANSISTOR
Q
962 2SB1322/RS/-T TRANSISTOR
Q
963 2SA1037AK/RS/-X TRANSISTOR
Q
964 DTC114EKA-X TR
Q
965 DTC114EKA-X TR
Q
966 DTC114EKA-X TR
Q
967 2SA1037AK/RS/-X TRANSISTOR
Q
978 DTC114EKA-X TR
Q
979 DTA114EKA-X DIGITAL.TRANSIS
Q
980 DTC114EKA-X TR
Q
981 DTA114EKA-X DIGITAL.TRANSIS
R 3 NRSA02J-472X MG RESISTOR
R 4 NRSA02J-473X MG RESISTOR
R 5 NRSA02J-332X MG RESISTOR
R 7 NRSA02J-473X MG RESISTOR
R 8 NRSA02J-472X MG RESISTOR
R 9 NRSA02J-102X MG RESISTOR
R 10 NRSA02J-392X MG RESISTOR
R 12 NRSA02J-102X MG RESISTOR
R 14 NRS181J-471X MG RESISTOR
R 24 NRSA02J-102X MG RESISTOR
R 25 NRSA02J-102X MG RESISTOR
R 26 NRSA02J-103X MG RESISTOR
R 27 NRSA02J-102X MG RESISTOR
R 29 NRSA02J-152X MG RESISTOR
R 30 NRS181J-8R2X MG RESISTOR
R 32 NRSA02J-0R0X MG RESISTOR
R 34 NRSA02J-223X MG RESISTOR
R 101 NRSA02J-153X MG RESISTOR
R 103 NRSA02J-101X MG RESISTOR
R 104 NRSA02J-334X MG RESISTOR
R 112 NRSA02J-223X MG RESISTOR
R 113 NRSA02J-222X MG RESISTOR
R 132 NRSA02J-222X MG RESISTOR
R 135 NRSA02J-101X MG RESISTOR
R 136 NRSA02J-102X MG RESISTOR
R 141 NRSA02J-153X MG RESISTOR
R 142 NRSA02J-153X MG RESISTOR
R 143 NRSA02J-393X MG RESISTOR
R 144 NRSA02J-393X MG RESISTOR
R 151 NRSA02J-103X MG RESISTOR
R 152 NRSA02J-223X MG RESISTOR
R 153 NRSA02J-472X MG RESISTOR
R 201 NRSA02J-153X MG RESISTOR
R 203 NRSA02J-101X MG RESISTOR
R 204 NRSA02J-334X MG RESISTOR
R 212 NRSA02J-223X MG RESISTOR
R 213 NRSA02J-222X MG RESISTOR
R 232 NRSA02J-222X MG RESISTOR
R 235 NRSA02J-101X MG RESISTOR
R 236 NRSA02J-102X MG RESISTOR
R 241 NRSA02J-153X MG RESISTOR
R 242 NRSA02J-153X MG RESISTOR
R 243 NRSA02J-393X MG RESISTOR
R 244 NRSA02J-393X MG RESISTOR
R 251 NRSA02J-103X MG RESISTOR
R 252 NRSA02J-223X MG RESISTOR
R 253 NRSA02J-472X MG RESISTOR
R 301 NRSA02J-473X MG RESISTOR S
Q
USE
R 302 NRSA02J-473X MG RESISTOR S
Q
USE
R 303 NRSA02J-103X MG RESISTOR S
Q
USE
R 304 NRSA02J-222X MG RESISTOR S
Q
USE
R 305 NRSA02J-153X MG RESISTOR S
Q
USE
R 306 NRSA02J-471X MG RESISTOR S
Q
USE
R 307 NRSA02J-103X MG RESISTOR S
Q
USE
R 701 NRSA02J-271X MG RESISTOR
R 702 NRS181J-271X MG RESISTOR
R 703 NRS181J-271X MG RESISTOR
R 704 NRSA02J-271X MG RESISTOR
R 705 NRSA02J-103X MG RESISTOR
R 706 NRSA02J-473X MG RESISTOR
R 708 NRSA02J-104X MG RESISTOR
R 709 NRSA02J-104X MG RESISTOR
R 710 NRS181J-472X MG RESISTOR
R 711 NRSA02J-391X MG RESISTOR
R 712 NRS181J-103X MG RESISTOR
R 713 NRSA02J-103X MG RESISTOR
R 715 NRS181J-103X MG RESISTOR
R 716 NRS181J-103X MG RESISTOR
R 717 NRS181J-103X MG RESISTOR
R 718 NRS181J-472X MG RESISTOR
R 719 NRSA02J-472X MG RESISTOR
R 720 NRSA02J-472X MG RESISTOR
R 721 NRS181J-472X MG RESISTOR
R 722 NRSA02J-472X MG RESISTOR
R 723 NRS181J-472X MG RESISTOR
R 724 NRS181J-472X MG RESISTOR
R 725 NRS181J-472X MG RESISTOR
Item
Parts number Parts name Area
Remarks
A
IC
