KS-FX483R/KS-FX480R/KS-FX43R
3-12
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
R 731 NRSA63J-472X MG RESISTOR
INTI. RES.
R 732 NRSA63J-473X MG RESISTOR
INTI. RES.
R 733 NRS181J-473X MG RESISTOR
R 734 NRS181J-103X MG RESISTOR
R 736 NRSA63J-103X MG RESISTOR
R 737 NRSA63J-473X MG RESISTOR
R 738 NRSA63J-473X MG RESISTOR
R 740 NRSA63J-473X MG RESISTOR
R 743 NRSA63J-103X MG RESISTOR
S
USE
R 746 NRSA63J-473X MG RESISTOR
R 747 NRSA63J-473X MG RESISTOR
INTI. RES.
R 974 NRSA63J-123X MG RESISTOR
R 975 NRSA63J-243X MG RESISTOR
R 977 NRSA63J-181X MG RESISTOR
R 979 NRSA63J-473X MG RESISTOR
R 980 NRSA63J-102X MG RESISTOR
R 982 NRSA63J-472X MG RESISTOR
TU 1 QAU0292-001 TUNER PACK
X 701 QAX0406-002Z CRYSTAL
X 761 QAX0263-001Z CRYSTAL
R 748 NRSA63J-103X MG RESISTOR
INTI. RES.
R 750 NRSA63J-473X MG RESISTOR
INTI. RES.
R 752 NRSA63J-334X MG RESISTOR
R 753 NRSA63J-223X MG RESISTOR
R 754 NRSA63J-101X MG RESISTOR
R 755 NRSA63J-103X MG RESISTOR
R 756 NRSA63J-104X MG RESISTOR
R 757 NRSA63J-104X MG RESISTOR
R 758 NRSA63J-101X MG RESISTOR
R 759 NRSA63J-334X MG RESISTOR
R 761 NRSA63J-222X MG RESISTOR
R 762 NRSA63J-222X MG RESISTOR
R 763 NRSA63J-222X MG RESISTOR
R 764 NRSA63J-222X MG RESISTOR
FX43R
R 765 NRS181J-223X MG RESISTOR
FX43R
R 772 NRSA63J-473X MG RESISTOR
R 773 NRSA63J-473X MG RESISTOR
R 779 NRSA63J-473X MG RESISTOR
R 911 NRSA63J-271X MG RESISTOR
R 912 NRSA63J-271X MG RESISTOR
R 913 NRSA63J-100X MG RESISTOR
R 941 NRSA63J-473X MG RESISTOR
R 959 NRSA63J-222X MG RESISTOR
R 960 NRSA63J-273X MG RESISTOR
R 961 QRE141J-470Y C RESISTOR
47 5% 1/4W
R 962 NRSA63J-682X MG RESISTOR
R 963 NRSA63J-123X MG RESISTOR
R 966 NRSA63J-473X MG RESISTOR
R 967 NRSA63J-222X MG RESISTOR
R 969 NRS181J-222X MG RESISTOR
R 970 NRSA63J-473X MG RESISTOR
R 971 NRS181J-222X MG RESISTOR
R 972 NRS181J-222X MG RESISTOR
