KS-FX621
3-9
Front board
Block No. [0][2][0][0]
R33 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R34 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R35 QRE141J-152Y C RESISTOR 1.5k
Ω
1/4W J
R36 QRE141J-471Y C RESISTOR 470
Ω
1/4W J
R81 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R82 QRE141J-682Y C RESISTOR 6.8k
Ω
1/4W J
R91 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R92 QRE141J-682Y C RESISTOR 6.8k
Ω
1/4W J
R161 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R162 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R163 QRE141J-392Y C RESISTOR 3.9k
Ω
1/4W J
R164 QRE141J-122Y C RESISTOR 1.2k
Ω
1/4W J
R171 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R172 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R173 QRE141J-392Y C RESISTOR 3.9k
Ω
1/4W J
R174 QRE141J-122Y C RESISTOR 1.2k
Ω
1/4W J
R195 QRE141J-100Y C RESISTOR 10
Ω
1/4W J
R241 QRE141J-154Y C RESISTOR 150k
Ω
1/4W J
R242 QRE141J-154Y C RESISTOR 150k
Ω
1/4W J
R243 QRE141J-184Y C RESISTOR 180k
Ω
1/4W J
R244 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R245 QRE141J-123Y C RESISTOR 12k
Ω
1/4W J
R246 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
R247 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R248 QRE141J-563Y C RESISTOR 56k
Ω
1/4W J
R301 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R303 QRE141J-272Y C RESISTOR 2.7k
Ω
1/4W J
R321 QRE141J-273Y C RESISTOR 27k
Ω
1/4W J
R322 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R325 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R331 QRE141J-273Y C RESISTOR 27k
Ω
1/4W J
R332 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R341 QRE141J-273Y C RESISTOR 27k
Ω
1/4W J
R342 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R343 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R344 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
R351 QRE141J-273Y C RESISTOR 27k
Ω
1/4W J
R352 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R353 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R354 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
R355 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R701 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R702 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R703 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R704 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R705 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R706 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R708 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R709 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R710 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R711 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R712 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R713 QRE141J-563Y C RESISTOR 56k
Ω
1/4W J
R714 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R716 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R717 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R718 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R719 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R720 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R721 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R722 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R723 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R724 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R725 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R727 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R728 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R729 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R730 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R731 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R734 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R735 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R736 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R737 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R738 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R743 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R750 QRE141J-683Y C RESISTOR 68k
Ω
1/4W J
R801 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
R802 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
Symbol No.
Part No. Part Name Description Local
R803 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
R804 QRE141J-334Y C RESISTOR 330k
Ω
1/4W J
R805 QRE141J-334Y C RESISTOR 330k
Ω
1/4W J
R806 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
R807 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
R808 QRE141J-223Y C RESISTOR 22k
Ω
1/4W J
R809 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R810 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
R811 QRE141J-682Y C RESISTOR 6.8k
Ω
1/4W J
R812 QRE141J-242Y C RESISTOR 2.4k
Ω
1/4W J
R813 QRE141J-242Y C RESISTOR 2.4k
Ω
1/4W J
R814 QRE141J-682Y C RESISTOR 6.8k
Ω
1/4W J
R901 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
R902 QRE141J-682Y C RESISTOR 6.8k
Ω
1/4W J
R903 QRE141J-113Y C RESISTOR 11k
Ω
1/4W J
R908 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R909 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R910 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R976 QRE141J-433Y C RESISTOR 43k
Ω
1/4W J
R977 QRE141J-683Y C RESISTOR 68k
Ω
1/4W J
R978 QRE141J-273Y C RESISTOR 27k
Ω
1/4W J
R979 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
L1 QQL231K-4R7Y INDUCTOR I/M 4.7uH K
L901 QQR0703-001 CHOKE COIL
L902 QQL231K-470Y INDUCTOR I/M 47uH K
L903 QQL231K-470Y INDUCTOR I/M 47uH K
CJ321 QNN0519-001 PIN JACK
CJ701 VMC0334-001 CONNECTOR
CP701 QGB1214J1-18S CONNECTOR B-B (1-18)
CP801 QNZ0095-001 CONNECTOR
CP981 QNZ0611-001 16P CONNECTOR
J1 QNB0100-002 CAR ANT JACK
TU1 QAU0281-001 TUNER PACK
X701 QAX0406-001Z CRYSTAL
Symbol No.
Part No. Part Name Description Local
IC651 PT6523LQ IC
IC652 RPM6938-SV4 REMOCON RCV
D601 SML-310LT/MN/-X LED
D602 LNJ308G81/1-3/X LED
D603 LNJ308G81/1-3/X LED
D604 LNJ308G81/1-3/X LED
D605 LNJ308G81/1-3/X LED
D606 LNJ308G81/1-3/X LED
D607 LNJ308G81/1-3/X LED
D608 SML-310VT/JK/-X LED
D609 LNJ308G81/1-3/X LED
D610 LNJ308G81/1-3/X LED
D611 LNJ308G81/1-3/X LED
D612 LNJ308G81/1-3/X LED
D613 LNJ308G81/1-3/X LED
D614 LNJ308G81/1-3/X LED
D615 LNJ308G81/1-3/X LED
D616 LNJ308G81/1-3/X LED
D617 LNJ308G81/1-3/X LED
D618 LNJ308G81/1-3/X LED
D619 LNJ308G81/1-3/X LED
D620 LNJ308G81/1-3/X LED
D640 NSPW310BS/B2RS/ LED
D641 NSPW310BS/B2RS/ LED
D651 UDZS5.6B-X Z DIODE 1.5k
Ω
1/10W J
D652 MA152WA-X DIODE
D653 MA152WA-X DIODE
D654 MA152WK-X DIODE
D655 MA152WK-X DIODE
D657 MA3062/H/-X Z DIODE
Symbol No.
Part No. Part Name Description Local
