KS-FX621
3-10
Mecha control board
Block No. [0][3][0][0]
C651 NCB21HK-223X C CAPACITOR 0.022uF 50V K
C652 NBE20JM-106X TS E CAPACITOR 10uF 6.3V M
C653 NCB21HK-681X C CAPACITOR 680pF 50V K
C654 NBE20JM-475X TS E CAPACITOR 4.7uF 6.3V M
D651 UDZS5.6B-X Z DIODE 1.5k
Ω
1/10W J
R601 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R602 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R603 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R604 NRSA63J-911X MG RESISTOR 910
Ω
1/16W J
R605 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R607 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R608 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R609 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R610 NRSA63J-911X MG RESISTOR 910
Ω
1/16W J
R611 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R612 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R613 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R614 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R615 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R616 NRSA63J-911X MG RESISTOR 910
Ω
1/16W J
R617 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R618 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R630 NRS181J-331X MG RESISTOR 330
Ω
1/8W J
R631 NRS181J-331X MG RESISTOR 330
Ω
1/8W J
R635 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R636 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R637 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R638 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R639 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R640 NRSA02J-122X MG RESISTOR 1.2k
Ω
1/10W J
R641 NRSA02J-122X MG RESISTOR 1.2k
Ω
1/10W J
R642 NRSA02J-221X MG RESISTOR 220
Ω
1/10W J
R643 NRSA02J-221X MG RESISTOR 220
Ω
1/10W J
R644 NRSA02J-221X MG RESISTOR 220
Ω
1/10W J
R645 NRSA02J-221X MG RESISTOR 220
Ω
1/10W J
R646 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R647 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R648 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R649 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R652 NRSA02J-473X MG RESISTOR 47k
Ω
1/10W J
R653 NRSA02J-184X MG RESISTOR 180k
Ω
1/10W J
R654 NRSA02J-103X MG RESISTOR 10k
Ω
1/10W J
R655 NRSA02J-103X MG RESISTOR 10k
Ω
1/10W J
R656 NRSA02J-103X MG RESISTOR 10k
Ω
1/10W J
R657 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R658 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R659 NRSA02J-222X MG RESISTOR 2.2k
Ω
1/10W J
R660 NRSA02J-222X MG RESISTOR 2.2k
Ω
1/10W J
R661 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
CP701 VMC0335-001 PANEL CONNECTOR
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S618 NSW0124-001X TACT SW
S619 NSW0124-001X TACT SW
S620 NSW0124-001X TACT SW
S621 NSW0124-001X TACT SW
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
IC401 CXA2559Q IC
IC402 LB1641 IC
Q402 UN2211-X TRANSISTOR
Q403 2SB1322/RS/-T TRANSISTOR
D401 MA3047/H/-X Z DIODE
D402 1A3G-T1 SI DIODE
C401 NDC31HJ-101X C CAPACITOR 100pF 50V J
C402 NDC31HJ-101X C CAPACITOR 100pF 50V J
C403 NDC31HJ-101X C CAPACITOR 100pF 50V J
C404 NDC31HJ-101X C CAPACITOR 100pF 50V J
C405 NDC31HJ-101X C CAPACITOR 100pF 50V J
C406 NDC31HJ-101X C CAPACITOR 100pF 50V J
C407 NDC31HJ-101X C CAPACITOR 100pF 50V J
C408 NDC31HJ-101X C CAPACITOR 100pF 50V J
C409 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C410 QFV61HJ-153Z MF CAPACITOR 0.015uF 50V J
C411 QFV61HJ-153Z MF CAPACITOR 0.015uF 50V J
C412 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C413 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C414 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C415 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C418 NDC31HJ-221X C CAPACITOR 220pF 50V J
C419 QEKJ1HM-474Z E CAPACITOR 0.47uF 50V M
C421 NCB31HK-183X C CAPACITOR 0.018uF 50V K
C422 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C423 QERF1CM-106Z E CAPACITOR 10uF 16V M
C424 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C425 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R401 NRS181J-681X MG RESISTOR 680
Ω
1/8W J
R402 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R403 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R404 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R405 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R406 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R407 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R408 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R409 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R410 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R411 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R412 NRSA02J-101X MG RESISTOR 100
Ω
1/10W J
R413 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R414 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R415 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R416 NRSA63J-155X MG RESISTOR 1.5M
Ω
1/16W J
R417 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R418 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R422 NRSA02J-332X MG RESISTOR 3.3k
Ω
1/10W J
R423 NRS181J-473X MG RESISTOR 47k
Ω
1/8W J
R424 NRSA02J-332X MG RESISTOR 3.3k
Ω
1/10W J
R425 NRS181J-330X MG RESISTOR 33
Ω
1/8W J
CN401 QGB1214K1-18S CONNECTOR B-B (1-18)
CN402 QGA2001C1-06 CONNECTOR W-B (1-6)
CN403 QGF1219F1-10S CONNECTOR FFC/FPC (1-10)
To Next Page
