Widescreen monitor
1 IR transmitters
2 Disc loading slot
3 Dome light
4 Screen compartment
5 Screen (Liquid crystal panel)
6 0 (eject) button
7
(play/pause) button
8 4 (reverse skip) button
9 ¢ (forward skip) button
p MODE button
Parts identification
q (standby) button
• Turns on the power if pressed.
• Turns off the power if pressed and held.
w Remote sensor
e Open button
r Dome light switch
• See “To activate the door sensor” on page
12.
t AV1 INPUT terminals
When you watch the screen at an angle, the picture might not be clear. This is not a malfunction.
The finest picture can be seen when you watch the screen straight-on.
