JVC LCT2141-001A-H

14
371.5
370
102
1.5
1
2
16 92 122.5
287
368
334 (Front foot)
300 (Mid foot)
296 (Rear foot)
310
*
*
217
TM-A14E
PHASE CHROMA BRIGHT CONTRAST MENU
INPUT SELECT
VOLUME/SELECT
+
B A
POWER
–
_ON
—OFF
7 Dimensions Unit : mm
< Front View >
< Side View >
7 Y/C (Mini DIN 4 pin) terminal specifi cation
Pin No. Signal
1 GND (Y)
2 GND (C)
3Y
4C
4
2
3
1
Y/C IN
* Asterisks (
∗
) are used to indicate front panel
dimensions.
