(No.YA711<Rev.001>)3-3
EXPLODED VIEW PARTS LIST
Ref.No. Part No. Part Name Description Local
1B1 FU-N7XT3KVM DVD MECHA SLOT
A 1 FU-1EM123674 FRONT CABINET
A 3 FU-1EM325657 CONTROL PLATE
A 4 FU-1EM023466 REAR CABINET
A 5 FU-1EM223304 DECORATION PLATE
A 7 FU-1ESA20125 STAND ASSEMBLY
A 8 FU-1EM428257 JACK LABEL
A 9 FU-1EM222783 JACK HOLDER(A)
A 10 FU-1EM222784 JACK HOLDER(D)
A 14 ----------- POP LABEL
A 15 ----------- CAUTION LABEL
B 1 FU-1EM222764 SHIELD BOX
B 2 FU-1EM325619 STAND HOLDER
B 3 FU-1EM323797 WALL MOUNT BRACKET (x4)
B 7 FU-1EM425861 GASKET (x4)
B 8 FU-1EM325677 SPEAKER HOLDER (x2)
B 9 ----------- LASER CAUTION LABEL
B 10 FU-1EM428797 FELT
B 11 FU-1EM123213 DVD HOLDER
L 1 FU-GBHP3100 SCREW (x14)
L 2 FU-GBJP3080 SCREW (x4)
L 3 FU-GBJS3060 SCREW (x15)
L 4 FU-GBHS3080 SCREW (x7)
L 6 FU-GCJP3120 SCREW (x3)
L 8 FU-1EM420633A ASSEMBLED SCREW (x4)
L 9 FU-FPH34100 SCREW M4x10(x4)
L 11 FU-1EM422042 HEX SCREW (x2)
L 12 FU-1EM424392A ASSEMBLED SCREW (x4)
L 17 FU-1ESA19526 STAND SCREW KIT Inc.PolyBag(x3)
LCD1 FU-UH19MXA LCD MODULE
SP1 FU-DS16070XQ001 SPEAKER
SP2 FU-DS16070XQ001 SPEAKER
WR 1 FU-WX1A94N0-105 WIRE ASSEMBLY
WR 2 FU-WX1A94F0-101 WIRE ASSEMBLY
WR 3 FU-WX1A94N0-112 WIRE ASSEMBLY
WR 4 FU-WX1A94N0-103 WIRE ASSEMBLY
WR 5 FU-WX1A94F0-101 WIRE ASSEMBLY
WR 6 FU-WX1A94F0-111 WIRE ASSEMBLY
WR 7 FU-WX1A94N0-106 WIRE ASSEMBLY
WR 8 FU-WX1A94F0-101 WIRE ASSEMBLY
PB 1 FU-1ESA21430 MAIN PWB
PB 2 FU-1ESA20948-1 JACK PWB
PB 3 FU-1ESA20948-2 FUNCTION PWB
PB 4 FU-1ESA20948-3 JUNCTION-A PWB
PB 5 FU-1ESA20948-4 JUNCTION-B PWB
PB 6 FU-1ESA20948-5 JUNCTION-C PWB
PB 7 FU-1ESA19805 DIGITAL MAIN PWB UNIT
PB 8 FU-N7EX2KUP DVD MAIN PWB UNIT
To Next Page
