(No.YA711<Rev.001>)3-7

D907 FU-QDTZ001SS133 SI DIODE

D908 FU-NDQZ001N4005 SI DIODE

D909 FU-NDQZ001N4005 SI DIODE

C1001 FU-CA1J222TU061 C CAPACITOR 2200pF 50V

C1002 FU-CA2A223DT018 CAPACITOR 0.022uF 100V J

C1003 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K

C1004 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K

C1005 FU-CA2A223DT018 CAPACITOR 0.022uF 100V J

C1006 FU-CCE1000TE009 C CAPACITOR 10pF 6KV

C1007 FU-CA1J222TU061 C CAPACITOR 2200pF 50V

C1008 FU-CCE1000TE009 C CAPACITOR 10pF 6KV

C1009 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M

C1010 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M

C1011 FU-CE1GMZPDL102 E CAPACITOR 1000uF 35V M

C1012 FU-CCD2JKS0B221 C CAPACITOR 220pF 500V

C1014 FU-CCE1000TE009 C CAPACITOR 10pF 6KV

C1015 FU-CCE1000TE009 C CAPACITOR 10pF 6KV

C1016 FU-CHD1JK30B682 C CAPACITOR 6800pF 50V

C1018 FU-CHD1JK30B104 C CAPACITOR 0.1uF 50V

C1019 FU-CCD2JKS0B221 C CAPACITOR 220pF 500V

C1020 FU-CHD1JK30B104 C CAPACITOR 0.1uF 50V

C1023 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M

C1024 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K

C1025 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K

C1026 FU-CHD1JK30B104 C CAPACITOR 0.1uF 50V

C1027 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M

C1028 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K

C1031 FU-CA2A272DT018 CAPACITOR 0.0027uF 100V J

C1032 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K

C1033 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M

C1034 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K

C1035 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K

C1037 FU-CHD1CK30B105 C CAPACITOR 1uF 16V

C1038 FU-CHD1JK30B104 C CAPACITOR 0.1uF 50V

C1039 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K

C1040 FU-CHD1JK30B102 C CAPACITOR 1000pF 50V K

C1041 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K

C1042 FU-CHD1JZ30F224 C CAPACITOR 0.22uF 50V

C1043 FU-CHD1CK30B224 C CAPACITOR 0.22uF 16V

C1044 FU-CHD1JK30B104 C CAPACITOR 0.1uF 50V

C1045 FU-CHD1JK30B104 C CAPACITOR 0.1uF 50V

C1052 FU-CHD1JK30B104 C CAPACITOR 0.1uF 50V

C1053 FU-CE1EMASSL101 E CAPACITOR 100uF 25V M

C1054 FU-CHD1JK30B104 C CAPACITOR 0.1uF 50V

C1056 FU-CHD1JK30B104 C CAPACITOR 0.1uF 50V

C201 FU-CE1EMASDL471 E CAPACITOR 470uF 25V M

C202 FU-CHD1JK30B103 C CAPACITOR 0.01uF 50V K

C203 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C204 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M

C207 FU-CE1JMASDL100 E CAPACITOR 10uF 50V M

C209 FU-CE1EMASDL470 E CAPACITOR 47uF 25V M

C214 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J

C215 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C216 FU-CHD1CK30B105 C CAPACITOR 1uF 16V

C217 FU-CE1EMASDL470 E CAPACITOR 47uF 25V M

C218 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C219 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C220 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C221 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C301 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C302 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C303 FU-CE1AMASDL331 E CAPACITOR 330uF 10V M

C304 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C305 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C306 FU-CE1JMASDL220 E CAPACITOR 22uF 50V M

C309 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J

C310 FU-CHD1JJ3CH470 C CAPACITOR 47pF 50V J

C311 FU-CHD1JJ3CH470 C CAPACITOR 47pF 50V J

C401 FU-CE1JMASDL1R0 E CAPACITOR 1uF 50V M



C601 FU-CT2F474DC004 MF CAPACITOR 0.47uF 300V K

C603 FU-CEA271DYG005 C CAPACITOR 270uF 200V

C604 FU-CA2A393DT018 CAPACITOR 0.039uF 100V J

C605 FU-CA2A122DT018 CAPACITOR 0.0012uF 100V J

C606 FU-CA3D561PAN04 C CAPACITOR 560pF 2KV

C607 FU-CA2A823DT018 CAPACITOR 0.082uF 100V J

C608 FU-CA2A182DT018 CAPACITOR 0.0018uF 100V J

C631 FU-CE1EMASDL471 E CAPACITOR 470uF 25V M

C632 FU-CE1GMZPDL102 E CAPACITOR 1000uF 35V M

C633 FU-CCD3AKN0B152 C CAPACITOR 1500pF 1KV



C636 FU-CE1EMASDL101 E CAPACITOR 100uF 25V M

C638 FU-CE0KMZPDL222 E CAPACITOR 2200uF 6.3V M

C639 FU-CE1AMZPDL222 E CAPACITOR 2200uF 10V M

C640 FU-CE1AMASDL102 E CAPACITOR 1000uF 10V M

C641 FU-CE1AMZPDL332 E CAPACITOR 3300uF 10V M

C643 FU-CE1EMZPDL102 E CAPACITOR 1000uF 25V M

C645 FU-CA2A222DT018 CAPACITOR 0.0022uF 100V J

C646 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C647 FU-CE1AMAVSL101 E CAPACITOR 100uF 10V M



Ref No. Part No. Part Name Description Local

C648 FU-CE1EMAVSL470 E CAPACITOR 47uF 25V M

C649 FU-CE1AMAVSL221 E CAPACITOR 220uF 10V M

C650 FU-CE1AMAVSL221 E CAPACITOR 220uF 10V M

C652 FU-CE0KMASDL102 E CAPACITOR 1000uF 6.3V M

C653 FU-CE1JMASDL220 E CAPACITOR 22uF 50V M

C654 FU-CE1CMASDL101 E CAPACITOR 100uF 16V M

C655 FU-CE1JMAVSL1R0 E CAPACITOR 1uF 50V M

C656 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C661 FU-CE1JMASDL3R3 E CAPACITOR 3.3uF 50V M

C681 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C682 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C683 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C684 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C685 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V



C691 FU-CA2E472MR101 C CAPACITOR 4700pF 250V



C692 FU-CA2E222MR101 CAPACITOR 2200pF 250V K

C802 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C805 FU-CE1EMASDL331 E CAPACITOR 330uF 25V M

C806 FU-CE1EMASDL331 E CAPACITOR 330uF 25V M

C807 FU-CHD1EK30B223 C CAPACITOR 0.022uF 25V

C808 FU-CHD1EK30B223 C CAPACITOR 0.022uF 25V

C809 FU-CHD1CK30B105 C CAPACITOR 1uF 16V

C810 FU-CHD1CK30B105 C CAPACITOR 1uF 16V

C811 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C812 FU-CE1EMASDL471 E CAPACITOR 470uF 25V M

C813 FU-CE1EMASDL101 E CAPACITOR 100uF 25V M

C816 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J

C817 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J

C825 FU-CHD1CK30B105 C CAPACITOR 1uF 16V

C826 FU-CHD1JJ3CH391 C CAPACITOR 390pF 50V

C827 FU-CHD1CK30B105 C CAPACITOR 1uF 16V

C828 FU-CHD1JJ3CH391 C CAPACITOR 390pF 50V

C829 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J

C830 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J

C831 FU-CE1CMASDL101 E CAPACITOR 100uF 16V M

C832 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C833 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C906 FU-CHD1JJ3CH391 C CAPACITOR 390pF 50V

C907 FU-CHD1JJ3CH391 C CAPACITOR 390pF 50V

C910 FU-CE1EMASDL470 E CAPACITOR 47uF 25V M

C911 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C912 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C914 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C915 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C916 FU-CE0KMASDL102 E CAPACITOR 1000uF 6.3V M

C917 FU-CE0KMASDL221 E CAPACITOR 220uF 6.3V M

C918 FU-CE1AMASDL101 E CAPACITOR 100uF 10V M

C919 FU-CE1JMASDL220 E CAPACITOR 22uF 50V M

C920 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

C922 FU-CHD1CK30B105 C CAPACITOR 1uF 16V

C923 FU-CHD1JJ3CH271 C CAPACITOR 270pF 50V

C924 FU-CHD1CK30B105 C CAPACITOR 1uF 16V

C925 FU-CHD1JJ3CH271 C CAPACITOR 270pF 50V

C926 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J

C927 FU-CHD1JJ3CH102 C CAPACITOR 1000pF 50V J

C928 FU-CE1CMASDL101 E CAPACITOR 100uF 16V M

C929 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V

R1001 FU-RCX4222T1001 C RESISTOR 2.2k

Ω

1/4W J

R1002 FU-RCX4181T1001 C RESISTOR 180

Ω

1/4W J

R1003 FU-RCX4222T1001 C RESISTOR 2.2k

Ω

1/4W J

R1004 FU-RRXAJR5Z0103 MG RESISTOR 10k

Ω

1/10W J

R1005 FU-RRXAJR5Z0223 MG RESISTOR 22k

Ω

1/10W J

R1006 FU-RCX4181T1001 C RESISTOR 180

Ω

1/4W J

R1007 FU-RCX4100T1001 C RESISTOR 10

Ω

1/4W J

R1008 FU-RCX4123T1001 C RESISTOR 12k

Ω

1/4W J

R1010 FU-RCX4100T1001 C RESISTOR 10

Ω

1/4W J

R1011 FU-RRXAJR5Z0123 MG RESISTOR 12k

Ω

1/10W J

R1012 FU-RCX4273T1001 C RESISTOR 27k

Ω

1/4W J

R1013 FU-RCX4123T1001 C RESISTOR 12k

Ω

1/4W J

R1014 FU-RCX4273T1001 C RESISTOR 27k

Ω

1/4W J

R1015 FU-RRXAJR5Z0103 MG RESISTOR 10k

Ω

1/10W J

R1017 FU-RCX4123T1001 C RESISTOR 12k

Ω

1/4W J

R1018 FU-RRXAJR5Z0391 MG RESISTOR 390

Ω

1/10W J

R1019 FU-RRXAJR5Z0391 MG RESISTOR 390

Ω

1/10W J

R1020 FU-RRXAJR5Z0102 MG RESISTOR 1k

Ω

1/10W J

R1022 FU-RRXAJR5Z0333 MG RESISTOR 33k

Ω

1/10W J

R1023 FU-RRXAJR5Z0103 MG RESISTOR 10k

Ω

1/10W J

R1024 FU-RRXAFR5H2202 MG RESISTOR 22k

Ω

1/10W F

R1025 FU-RRXAJR5Z0152 MG RESISTOR 1.5k

Ω

1/10W J

R1026 FU-RCX4222T1001 C RESISTOR 2.2k

Ω

1/4W J

R1027 FU-RRXAJR5Z0512 MG RESISTOR 5.1k

Ω

1/10W J

R1028 FU-RRXAJR5Z0102 MG RESISTOR 1k

Ω

1/10W J

R1029 FU-RCX4182T1001 C RESISTOR 1.8K

Ω

1/4W J

R1030 FU-RCX4123T1001 C RESISTOR 12k

Ω

1/4W J

R1031 FU-RCX4472T1001 C RESISTOR 4.7k

Ω

1/4W J



R1032 FU-RN02R33ZU001 OMF RESISTOR 0.33

Ω

2W J

R1035 FU-RRXAFR5H1001 MG RESISTOR 1k

Ω

1/10W F

R1036 FU-RRXAFR5H1502 MG RESISTOR 15k

Ω

1/10W F



Ref No. Part No. Part Name Description Local
