9
ENGLISH
Parts and functions
Right sideFront
Remote sensor
Power indicator
Red: Standby
Blue: On
POWER button
INPUT/ENTER button
VOL (VOLUME) +/– buttons
CH (CHANNEL)
/ buttons
MENU button
Rear
To display the menu screen.
Press MENU button to display the menu
screen.
CH (CHANNEL)
/ buttons, VOL
(VOLUME) +/– buttons and INPUT/
ENTER button can be used to select the
desired setting during the menu screen
operations.
AC INPUT jack
PC/DVI AUDIO IN jack
VIDEO IN jacks
(VIDEO/AUDIO (L(MONO)/R))
COMPONENT IN jacks
DIGITAL AUDIO COAXIAL OUT jack
ANT. (RF) IN jack
HEADPHONE jack
PC MONITOR IN jack
HDMI/DVI IN jack
FOR SERVICE PERSONNEL USE ONLY
Do NOT insert ANY USB device into
this port. Use of this port by other than
Service Personnel may void this products
warranty.
Left side
