Parts and functions
Right sideFront
Remote sensor
Power indicator
Red: Standby
Blue: On
(POWER) button
INPUT/ENTER button
CH (CHANNEL) /
PLAY ( ) button/MENU ▲
EJECT (
) button
CH (CHANNEL)
/
STOP ( ) button/MENU ▼
VOL (VOLUME) +/– buttons
/MENU ◀/▶
Press and hold both VOL (VOLUME) +/– at the same
time for 1 second to display the menu screen.
CH (CHANNEL)
/ buttons, VOL (VOLUME)
+/– buttons and INPUT/ENTER button can be used
to select the desired setting during the menu screen
operations.
Rear
AC INPUT jack
PC/DVI AUDIO IN jack
VIDEO IN jacks
(VIDEO/AUDIO (L(MONO)/R))
COMPONENT IN jacks
DIGITAL AUDIO COAXIAL OUT jack
ANT. (RF) IN jack
HEADPHONE jack
PC MONITOR IN jack
HDMI/DVI IN jack
FOR SERVICE PERSONNEL USE ONLY
Do NOT insert ANY USB device into
this port. Use of this port by other than
Service Personnel may void this products
warranty.
Left side
