(No.YA509)3-9
SW P.W. BOARD ASS'Y (SFT-7201A-U2)
LED P.W. BOARD ASS'Y (SFT-8901A-U2)
POWER P.W. BOARD ASS'Y (SFT-9002A-U2)
R9321 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9322 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9401 NRSA02J-680X MG RESISTOR 68
Ω
1/10W J
R9402 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9403 NRSA63D-273X MG RESISTOR 27k
Ω
1/16W D
R9404 NRSA63J-335X MG RESISTOR 3.3M
Ω
1/16W J
R9405 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9410 NRS181J-181X MG RESISTOR 180
Ω
1/8W J
R9421 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9422 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
RA7001 NRZ0034-103W NET RESISTOR 10k
Ω
1/32W J x4
RA7002 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
RA7003 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
RA7004 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
RA7007 NRZ0034-103W NET RESISTOR 10k
Ω
1/32W J x4
RA7008 NRZ0034-103W NET RESISTOR 10k
Ω
1/32W J x4
L1001 NQL79GM-220X COIL 22uH M
L1002 NQL79GM-100X COIL 10uH M
L1003 NQL093M-220X COIL 22uH M
L1004 NQL093M-180X COIL 18uH M
L6101 NQLF3EM-330X COIL 33uH M
L6102 NQLF3EM-330X COIL 33uH M
L6103 NQLF3EM-330X COIL 33uH M
L6104 NQLF3EM-330X COIL 33uH M
L7001 NQL79GM-100X COIL 10uH M
L7002 NQL79GM-100X COIL 10uH M
L7003 NQL79GM-100X COIL 10uH M
L7004 NQL79GM-100X COIL 10uH M
L7005 NQL79GM-100X COIL 10uH M
L7006 NQL79GM-100X COIL 10uH M
L7007 NQL79GM-100X COIL 10uH M
L7008 NQL79GM-2R2X COIL 2.2uH M
L7009 NQL79GM-2R2X COIL 2.2uH M
L7010 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L7011 NQL79GM-100X COIL 10uH M
L7012 NQL79GM-100X COIL 10uH M
L7013 NQL79GM-4R7X COIL 4.7uH M
L7014 NQL79GM-100X COIL 10uH M
L7015 NQL79GM-100X COIL 10uH M
L7016 NQL79GM-100X COIL 10uH M
L7017 NQL79GM-100X COIL 10uH M
L9201 NQLD7EM-150X COIL 15uH M
L9301 NQL98EM-150X COIL 15uH M
L9401 NQL98EM-150X COIL 15uH M
J1001 QNZ0419-001 21P CONNECTOR EXT-1
J1002 QNZ0419-001 21P CONNECTOR EXT-2
J1003 QNN0801-001 PIN JACK EXT-3
J8501 QNZ0900-001 HDMI CONNECTOR EXT-4
J8502 QNZ0900-001 HDMI CONNECTOR EXT-5
K1001 NQR0389-003X FERRITE BEADS
K1101 NQR0599-004X FERRITE BEADS
K1102 NQR0389-003X FERRITE BEADS
K1103 NQR0389-003X FERRITE BEADS
K1201 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K1202 NQR0389-003X FERRITE BEADS
K1203 NQR0389-003X FERRITE BEADS
K6101 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6102 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6103 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6104 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6111 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6112 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6113 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6114 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6115 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K7001 NQR0389-003X FERRITE BEADS
K7003 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K7004 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K7005 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K7006 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9151 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9161 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9162 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9201 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9202 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9301 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9302 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9401 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
LC7001 NQR0479-001X EMI FILTER
OT1 LC42056-001A SHADE SPACER
TU1001 QAU0488-002 TUNER
X7001 NAX0661-001X CRYSTAL 20.2MHz
Ref No. Part No. Part Name Description Local
Ref No. Part No. Part Name Description Local
D7001 UDZW6.2B-X Z DIODE
D7101 1SS355W-X DIODE
C7001 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7002 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R7001 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7002 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7003 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7004 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7005 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7101 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R7102 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R7103 NRSA02J-123X MG RESISTOR 12k
Ω
1/10W J
L7001 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L7002 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
J7001 QNS0097-001 HEADPHONE JACK
K7001 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
S7101 QSW1131-001Z TACT SWITCH POWER
S7102 QSW1131-001Z TACT SWITCH MENU
S7103 QSW1131-001Z TACT SWITCH CH-
S7104 QSW1131-001Z TACT SWITCH CH+
Ref No. Part No. Part Name Description Local
IC8952 GP1UM261RK IR DETECT UNIT
Q8901 RT1N241C-X DIGI TRANSISTOR
Q8902 RT1P440C-X DIGI TRANSISTOR
Q8903 RT1P440C-X DIGI TRANSISTOR
Q8904 RT1N241C-X DIGI TRANSISTOR
D8905 SML72420C-T LED POWER
C8901 NCB11AK-106X C CAPACITOR 10uF 10V K
C8951 NCB11AK-106X C CAPACITOR 10uF 10V K
C8953 NCB11AK-106X C CAPACITOR 10uF 10V K
R8901 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8902 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R8903 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R8904 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8951 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
Ref No. Part No. Part Name Description Local
IC9201 MIP2F30MSSCF IC
IC9202 S7805D-W IC
IC9501 STR-X6768N-F2 IC
Q9501 2SC1623A/5-6/-X SI TRANSISTOR
Q9502 RT1N241C-X DIGI TRANSISTOR
Q9503 2SC1623A/5-6/-X SI TRANSISTOR
Q9505 2SC1623A/5-6/-X SI TRANSISTOR
D9001 TS25P05G-C2 BRIDGE DIODE
D9203 EG01C-T2 SI DIODE
D9204 SSPX-66-W SI DIODE
D9205 TL431/A/-T IC
D9207 EC21QS10-X SB DIODE
D9208 FCH20A10 SB DIODE
D9215 MA8330/M/-X Z DIODE
D9216 MA8150/M/-X Z DIODE
D9217 MA8150/M/-X Z DIODE
D9501 UDZW5.1B-X SB DIODE
D9502 MTZJ33B-T2 Z DIODE
D9503 1SS355W-X DIODE
D9504 RF101L2S-X SI DIODE
D9505 RF101L2S-X SI DIODE
D9506 SARS01-T2 FR DIODE
D9507 SARS01-T2 FR DIODE
D9508 FR105GT-T3 SI DIODE
D9509 RL2Z-LFC4 SI DIODE
D9511 FMX-G22S SI DIODE
D9512 FMX-G22S SI DIODE
D9513 FMX-G22S SI DIODE
