3-4(No.YA408)
EXPLODED VIEW PARTS LIST -1 [26 inch / 32 inch models]
Ref.No. Part No. Part Name Description Local
101 LC12645-001A-U JACK COVER
LT-26DR7BJ,LT-26DR7BJP,LT-26DR7SJ,LT-26DR7SJP
101 LC12650-001A-U JACK COVER
LT-32DR7BJ,LT-32DR7BJP,LT-32DR7SJ,LT-32DR7SJP
102 GA10166-003A-U STAND ASSY
LT-26DR7BJ,LT-26DR7BJP,LT-32DR7BJ,LT-32DR7BJP
102 GA10166-001A-U STAND ASSY
LT-26DR7SJ,LT-26DR7SJP,LT-32DR7SJ,LT-32DR7SJP
103 QYSPSPD5014MA SCREW M5 x 14mm(x4)
104 LC12644-001A-U REAR COVER
LT-26DR7BJ,LT-26DR7BJP,LT-26DR7SJ,LT-26DR7SJP
104 LC12649-001A-U REAR COVER
LT-32DR7BJ,LT-32DR7BJP,LT-32DR7SJ,LT-32DR7SJP
105 QYSBSFG4016MA TAP SCREW M4 x 16mm(x7)
106 LC42446-002A SCREW
107 QYSBSF3010MA TAP SCREW M3 x 10mm(x5)
108 WJZ0192-001A-E E-HARNESS ASSY ANALOG UV UA-DIGITAL PL207 PL200
109 WJX0033-001A-E E-COAXIAL ASSY DIGITAL TUNER UNIT-RF SPLITTER
110 QAU0420-002 DIGITAL TUNER UNIT
111 QJJ064-100600-E SIN CR C-C WIRE ANALOG S-D-AMP CN00S
112 WJZ0207-002A-E E-HARNESS ASSY SPEAKER
113 QUQL05-5009AA-E FFC WIRE ANALOG CN001-DIGITAL CN001
114 QUQL05-4009AA-E FFC WIRE ANALOG CN002-DIGITAL CN002
115 QJJ009-151010-E SIN CR C-C WIRE DIGITAL CN0DC-DC-DC DC
116 WJJ0692-001A-E E-SI C WIRE C-C DIGITAL ID-DIGITAL TUNER UNIT
117 QQR0490-001 NOISE FILTER (x2)
118 LC42446-001A SCREW
119 LC42340-001B-HK SERVICE COVER
120 LC42446-001A SCREW
121 QYSPSP3004ZA SCREW M3 x 4mm
122 QNB0036-001 CONN ACCESSORY (x2)
123 LC12497-011A-HK SHIELD TERMINAL
124 QJJ009-150710-E SIN CR C-C WIRE ANALOG H-DC-DC H
125 QQR0490-001 NOISE FILTER (x2)
126 LC12507-005B-0K TUNER BASE
127 LC42446-002A SCREW (x2)
128 LC12506-005B-0K TERMINAL BASE
129 QYSBSF3010MA TAP SCREW M3 x 10mm(x3)
130 QNB0036-001 CONN ACCESSORY (x2)
131 QJJ009-151010-E SIN CR C-C WIRE POWER A-DC-DC 10A
132 QJJ015-043024-E SIN CR C-C WIRE POWER F-D-AMP CN10F
133 QMPN370-170-JC POWER CORD(EK) 1.7m BLACK
134 QQR0491-001 FERRITE CORE
135 LC22007-003A-0K POWER CORD HOLDER
136 LC33411-010A OPERATION SHEET
201 SFL-6222A-U2 D-AMP PWB
202 SFL0D264A-U2 DIGITAL PWB LT-26DR7BJ,LT-26DR7SJ
202 LCA10599-93B DIGITAL PWB LT-26DR7BJP,LT-26DR7SJP
202 SFL0D265A-U2 DIGITAL PWB LT-32DR7BJ,LT-32DR7SJ
202 LCA10599-94B DIGITAL PWB LT-32DR7BJP,LT-32DR7SJP
203 SFL-1247A-U2 ANALOG PWB
204 SFL-9152A-U2 DC-DC PWB
205 SFL-9046A-U2 POWER PWB
To Next Page
