3-6(No.YA408)
EXPLODED VIEW PARTS LIST -2 [26 inch / 32 inch models]
Ref.No. Part No. Part Name Description Local
151 QLD0430-001-JUK LCD PANEL UNIT LT-26DR7BJ,LT-26DR7BJP,LT-26DR7SJ,LT-26DR7SJP
151 QLD0431-001-JUK LCD PANEL UNIT LT-32DR7BJ,LT-32DR7BJP,LT-32DR7SJ,LT-32DR7SJP
152 WJW0045-002A-E DIGITAL (LVDS) CABLE DIGITAL CN0LV2-LCD PANEL UNIT
153 QQR0491-001 FERRITE CORE
154 WJZ0210-001A-E E-HARNESS ASSY POWER PWB P-LCD PANEL UNIT
155 QQR0491-001 FERRITE CORE LT-26DR7BJ,LT-26DR7BJP,LT-26DR7SJ,LT-26DR7SJP
156 LC12674-002A-U FRONT PANEL LT-26DR7BJ,LT-26DR7BJP
156 LC12674-001A-U FRONT PANEL LT-26DR7SJ,LT-26DR7SJP
156 LC12676-002A-U FRONT PANEL LT-32DR7BJ,LT-32DR7BJP
156 LC12676-001A-U FRONT PANEL LT-32DR7SJ,LT-32DR7SJP
157 LC33452-002A LED PLATE LT-26DR7BJ,LT-26DR7BJP,LT-32DR7BJ,LT-32DR7BJP
157 LC33452-003A LED PLATE LT-26DR7SJ
157 LC33452-001A LED PLATE LT-26DR7SJP,LT-32DR7SJ,LT-32DR7SJP
158 LC41852-001B JVC MARK ASSY
159 QAS0445-001 SPEAKER (x2) LT-26DR7BJ,LT-26DR7BJP,LT-26DR7SJ,LT-26DR7SJP
159 QAS0446-001 SPEAKER (x2) LT-32DR7BJ,LT-32DR7BJP,LT-32DR7SJ,LT-32DR7SJP
160 LC41458-002A TAPPING SCREW (x4)
161 QQR0490-001 NOISE FILTER
162 WJZ0224-003A-E E-HARNESS ASSY ANALOG R-SW CN100R LT-26DR7BJ,LT-26DR7BJP,LT-26DR7SJ,LT-26DR7SJP
162 WJZ0224-002A-E E-HARNESS ASSY ANALOG R-SW CN100R LT-32DR7BJ,LT-32DR7BJP,LT-32DR7SJ,LT-32DR7SJP
163 LC33404-001A-HK CONTROL ASSY
164 QQR0491-001 FERRITE CORE LT-26DR7BJ,LT-26DR7BJP,LT-26DR7SJ,LT-26DR7SJP
206 SFL-7206A-U2 SW PWB
207 SFL-8904A-U2 LED PWB
