Make sure all the devices and the TV are turned off.
The names of the devices shown in the following illustration are examples.
Note
Please read the user manuals of each device before setting up.
Connecting cables are not supplied with this TV.
When using EXT-2 terminal, some USB device may not able to connect
properly depending on the outside dimensions.
DVD player
Video camera
Game consoles
Audio system
Digital Satellite broadcast tuner
DVD player
HD Video camera
CI (Common Interface) slot
Refer to P. 8.
EXT-1
EXT-3
EXT-2
DIGITAL
AUDIO
OUT
EXT-4
(HDMI 1)
EXT-5
(HDMI 2)
EXT-6
(HDMI 3)
Find the best connections that are possible with
your devices. Æ (P. 10, 11)
A B
C
F
A
A
D
D
Connecting external devices
Not available (for service adjustments)
USB terminal
Refer to P. 35.
: type of connections
A B C D E F
E
EXT-1 Satellite broadcast tuner
EXT-2 VCR / DVD recorder
