Parts and functions
Right sideFront
Remote sensor
Power indicator
Red: Standby
Green: On
Press and hold both VOL (VOLUME) +/– at the same
time for 1 second to display the menu screen.
CH (CHANNEL)
/ buttons, VOL (VOLUME)
+/– buttons and INPUT/ENTER button can be used
to select the desired setting during the menu screen
operations.
Rear
AUDIO (L/R) IN jacks
COMPONENT IN
(Y(VIDEO)/Pb/Pr) jacks
COAXIAL OUT jack
ANT. (RF) IN jack
PC MONITOR IN jack
HDMI/DVI1/2 IN jacks
USB INPUT
Right side
AUDIO (L/R) OUT jacks
POWER button
INPUT/ENTER button
CH (CHANNEL)
/ /▲/▼ buttons
VOL (VOLUME) +/–/▶/◀/
MENU buttons
