(No.YA596<Rev.001>)3-3
EXPLODED VIEW PARTS LIST -1
Ref.No. Part No. Part Name Description Local
1 GG10567-001A-LK REAR COVER
2 GG10561-001A-HK FRONT PANEL
4 WJW0090-001A-E DIGITAL(LVDS) CABLE MAIN-LCD PANEL
5 QAS0548-001 SPEAKER (x2)
7 QMPK450-170-JC POWER CORD(EU) 1.7m BLACK
8 GG20205-001A-HK TERMINAL BASE
9 GG10571-001A-U MAIN BASE
11 GG20210-001B-HK BACK BRACKET (x2)
16 LC42877-010B STAND BASE UNIT
17 LC43033-001A-C SUPPORT UNIT
20 LC34049-001A-U POWER CORD COVER
21 GG30203-001A-HK CONTROL ASSY
33 GG30205-002A-HK LCD SUPPORT BKT (x2)
34 GG30205-001A-HK LCD SUPPORT BKT (x2)
38 GG10573-001A-U BOTTOM FRAME
50 QYSBSFG3014MA TAP SCREW M3 x 14mm(x12)
51 LC42784-002A SCREW (x8)
52 QYSBSFG3014MA TAP SCREW M3 x 14mm
57 LC42784-002A SCREW
58 QYSPSPD5008MA SCREW M5 x 8mm(x4)
59 QYSPSPD5008MA SCREW M5 x 8mm(x4)
60 QZW0156-002 WIRE CLAMP (x2)
61 QZW0302-001 EDGING (x2)
63 WJZ0319-001A-E WIRE MAIN-SPEAKER/MAIN-LED
65 WJZ0311-001A-E WIRE MAIN-POWER
66 GA40018-001A-U TWIST LOCK
67 QQR0490-001 NOISE FILTER
68 WJZ0318-001A-E WIRE POWER-LCD PANEL
72 GG40077-001A-HK PC SHEET
73 LC33848-017A-C SOFT GASKET
74 QAU0488-002 TUNER
100 SFT-9053A-H3 POWER PWB
102 SFT-1102A-H3 MAIN PWB
103 SFT-7210A-H3 SW PWB
104 SFT-8210A-H3 LED PWB
108 SFT-7301A-H3 REMOTE PWB
