JVC LT-42R90BU Service Manual

3-6(No.YA596<Rev.001>)
PRINTED WIRING BOARD PARTS LIST
MAIN P.W. BOARD ASS'Y (SFT-1102A-H3)
 Ref No. Part No. Part Name Description Local
IC1001 MM1510XN-X IC
IC1002 MM1510XN-X IC
IC1003 NJW1110V-X IC
IC1004 NJM4565M-WE IC
IC6001 TPA3100D2PHP-W IC
IC6011 BH3547F-X IC
IC6661 MX3000DS-X IC
IC6771 NJM4565M-WE IC
IC7002 S-80928CLNB-G-W IC
IC7003 ATF256-42R9BU IC (SERVICE)
IC7004 M62320GP1-X IC
IC7005 M62320GP1-X IC
IC8001 ATF02-42DR9BJA1 IC (SERVICE)
IC8101 ATF02-42DR9BJA2 IC (SERVICE)
IC8201 ATF02-42DR9BJA3 IC (SERVICE)
IC8501 TMDS351PAG IC
IC9101 MM1663DH-X IC
IC9151 PQ1MGX38MS-X IC
IC9201 SI-8005Q-X IC
IC9251 SI-8008TM-X IC
IC9301 SI-8005Q-X IC
IC9351 SI-8015Q-X IC
IC9511 S7809D-W IC
IC9601 SI-8005Q-X IC
IC9651 MM1662FH-X IC
IC9751 PQ1MGX38MS-X IC
Q1003 2SC1623A/5-6/-X TRANSISTOR
Q1004 2SC1623A/5-6/-X TRANSISTOR
Q1005 2SC1623A/5-6/-X TRANSISTOR
Q1101 2SA812A/5-6/-X TRANSISTOR
Q1102 RT4N430C-X DIGI TRANSISTOR
Q1103 RT4N430C-X DIGI TRANSISTOR
Q1201 2SA812A/5-6/-X TRANSISTOR
Q1202 RT4N430C-X DIGI TRANSISTOR
Q1203 RT4N430C-X DIGI TRANSISTOR
Q1204 2SC1623A/5-6/-X TRANSISTOR
Q1205 2SC1623A/5-6/-X TRANSISTOR
Q1301 2SA812A/5-6/-X TRANSISTOR
Q1302 RT4N430C-X DIGI TRANSISTOR
Q1303 RT4N430C-X DIGI TRANSISTOR
Q6105 RT1N441C-X TRANSISTOR
Q6106 2SC1623A/5-6/-X TRANSISTOR
Q6501 2SA812A/5-6/-X TRANSISTOR
Q6502 2SA812A/5-6/-X TRANSISTOR
Q6503 RT4N430C-X DIGI TRANSISTOR
Q7001 RT1P441C-X DIGI TRANSISTOR
Q7003 RT1P441C-X DIGI TRANSISTOR
Q7004 RT1P441C-X DIGI TRANSISTOR
Q7006 2SC1623A/5-6/-X TRANSISTOR
Q7007 2SC1623A/5-6/-X TRANSISTOR
Q7009 2SK3019-X MOS FET
Q7010 2SK3019-X MOS FET
Q7011 2SC1623A/5-6/-X TRANSISTOR
Q7013 RT1N441C-X TRANSISTOR
Q7014 2SC1623A/5-6/-X TRANSISTOR
Q7019 RT1N441C-X TRANSISTOR
Q8001 RT1P441C-X DIGI TRANSISTOR
Q8002 RT1N441C-X TRANSISTOR
Q8004 RT1N441C-X TRANSISTOR
Q8101 RT1P441C-X DIGI TRANSISTOR
Q8102 RT1N441C-X TRANSISTOR
Q8201 RT1P441C-X DIGI TRANSISTOR
Q8202 RT1N441C-X TRANSISTOR
Q9201 2SC1623A/5-6/-X TRANSISTOR
Q9301 2SC1623A/5-6/-X TRANSISTOR
Q9351 2SC1623A/5-6/-X TRANSISTOR
Q9601 2SC1623A/5-6/-X TRANSISTOR
D1101 UDZW5.6B-X Z DIODE
D1102 UDZW3.6B-X Z DIODE
D1103 UDZW8.2B-X Z DIODE
D1104 UDZW8.2B-X Z DIODE
D1105 UDZW3.6B-X Z DIODE
D1106 UDZW3.6B-X Z DIODE
D1107 UDZW3.6B-X Z DIODE
D1108 UDZW3.6B-X Z DIODE
D1109 UDZW3.6B-X Z DIODE
D1110 UDZW3.6B-X Z DIODE
D1111 UDZW8.2B-X Z DIODE
D1112 UDZW8.2B-X Z DIODE
D1113 UDZW5.6B-X Z DIODE
D1202 UDZW3.6B-X Z DIODE
D1203 UDZW5.6B-X Z DIODE
D1204 UDZW5.6B-X Z DIODE
D1205 UDZW8.2B-X Z DIODE
D1206 UDZW8.2B-X Z DIODE
D1209 MA111-X SI DIODE
D1210 UDZW8.2B-X Z DIODE
D1211 UDZW8.2B-X Z DIODE
D1217 UDZW3.6B-X Z DIODE
D1301 UDZW8.2B-X Z DIODE
D1302 UDZW8.2B-X Z DIODE
D1303 UDZW8.2B-X Z DIODE
D1304 UDZW8.2B-X Z DIODE
D1307 UDZW3.6B-X Z DIODE
D1308 UDZW3.6B-X Z DIODE
D1309 UDZW3.6B-X Z DIODE
D6101 1SS355W-X DIODE
D6104 1SS355W-X DIODE
D6501 1SS355W-X DIODE
D6502 1SS355W-X DIODE
D6503 1SS355W-X DIODE
D6771 UDZW6.2B-X Z DIODE
D7006 UDZW5.6B-X Z DIODE
D7007 UDZW5.6B-X Z DIODE
D7008 UDZW5.6B-X Z DIODE
D7009 UDZW5.6B-X Z DIODE
D7010 UDZW5.6B-X Z DIODE
D7011 UDZW5.6B-X Z DIODE
D7012 UDZW5.6B-X Z DIODE
D7013 UDZW5.6B-X Z DIODE
D7014 UDZW5.6B-X Z DIODE
D7019 UDZW8.2B-X Z DIODE
D7020 UDZW5.6B-X Z DIODE
D8001 MA111-X SI DIODE
D8002 MA111-X SI DIODE
D8101 MA111-X SI DIODE
D8102 MA111-X SI DIODE
D8201 MA111-X SI DIODE
D8202 MA111-X SI DIODE
D9201 RB055L-40-X SB DIODE
D9202 RB055L-40-X SB DIODE
D9203 PTZ6.8B-X Z DIODE
D9204 1SS355W-X DIODE
D9206 UDZW3.0B-X Z DIODE
D9251 RB055L-40-X SB DIODE
D9252 RB055L-40-X SB DIODE
D9253 PTZ3.9B-X Z DIODE
D9301 RB055L-40-X SB DIODE
D9302 RB055L-40-X SB DIODE
D9303 PTZ16B-X Z DIODE
D9304 1SS355W-X DIODE
D9351 RB055L-40-X SB DIODE
D9352 RB055L-40-X SB DIODE
D9353 PTZ3.9B-X Z DIODE
D9354 1SS355W-X DIODE
D9601 RB055L-40-X SB DIODE
D9602 RB055L-40-X SB DIODE
D9603 PTZ3.9B-X Z DIODE
D9605 1SS355W-X DIODE
C1001 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1002 NEHL1AM-107X E CAPACITOR 100uF 10V M
C1006 NCB31AK-105X C CAPACITOR 1uF 10V K
C1007 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1008 NEHL1HM-106X E CAPACITOR 10uF 50V M
C1009 NEHL1EM-106X E CAPACITOR 10uF 25V M
C1010 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1011 NCB31HK-821X C CAPACITOR 820pF 50V K
C1012 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1013 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1014 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1015 NDC31HJ-180X C CAPACITOR 18pF 50V J
C1016 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1017 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1101 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1102 NEHL1AM-107X E CAPACITOR 100uF 10V M
C1103 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1104 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1105 NCB31AK-105X C CAPACITOR 1uF 10V K
C1107 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1110 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1111 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1112 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1113 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1114 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1115 NCB31AK-105X C CAPACITOR 1uF 10V K
C1116 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1117 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1118 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1119 NCB31HK-104X C CAPACITOR 0.1uF 50V K
 Ref No. Part No. Part Name Description Local
