JVC LT-42R90BU Service Manual

(No.YA596<Rev.001>)3-11
SW P.W. BOARD ASS'Y (SFT-7210A-H3)
REMOTE P.W. BOARD ASS'Y (SFT-7301A-H3)
LED P.W. BOARD ASS'Y (SFT-8210A-H3)
POWER P.W. BOARD ASS'Y (SFT-9053A-H3)
 Ref No. Part No. Part Name Description Local
D7001 UDZW6.2B-X Z DIODE
D7101 1SS355W-X DIODE
C7001 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7002 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R7001 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7002 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7005 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7103 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7106 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R7107 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R7108 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7001 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L7002 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
J7001 QNS0072-001 HEADPHONE JACK
K7001 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
S7104 QSW1131-001Z TACT SWITCH POWER
S7105 QSW1131-001Z TACT SWITCH MENU
S7106 QSW1131-001Z TACT SWITCH CH+
S7107 QSW1131-001Z TACT SWITCH CH-
 Ref No. Part No. Part Name Description Local
IC7301 PIC96337 PHOTO CONDUCTOR
IC7302 GP1UE281RKC1 IR DETECT UNIT
D7301 UDZW5.6B-X Z DIODE
D7302 UDZW5.6B-X Z DIODE
C7302 QETN1EM-226Z E CAPACITOR 22uF 25V M
C7304 NCB11AK-106X C CAPACITOR 10uF 10V K
C7305 NCB11AK-106X C CAPACITOR 10uF 10V K
R7301 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7302 NRSA63J-394X MG RESISTOR 390k Ω 1/16W J
R7303 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R7304 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R7305 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
CN701G QJL001-062011-E SIN CR B-B WIRE
 Ref No. Part No. Part Name Description Local
Q8901 RT1N241C-X DIGI TRANSISTOR
Q8902 RT1P440C-X DIGI TRANSISTOR
D8901 SELT5E20CS/EF/T LED POWER
D8902 UDZW6.8B-X Z DIODE
D8903 UDZW6.8B-X Z DIODE
C8901 NCB11AK-475X C CAPACITOR 4.7uF 10V K
R8901 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R8902 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
IC9201 MIP2F30MSSCF IC
IC9203 TL431/A/-T IC
IC9501 MP2A5038-F233 IC
 IC9502 FA5500AN-W IC
IC9601 TL431/A/-T IC
IC9701 PQ1CG2032FZ IC
IC9751 PQ1CG2032FZ IC
Q9001 2SC1623A/5-6/-X TRANSISTOR
Q9002 2SC1623A/5-6/-X TRANSISTOR
Q9501 2SK3522A-01 POWER MOS FET
Q9502 2SC1623A/5-6/-X TRANSISTOR
Q9503 2SC1623A/5-6/-X TRANSISTOR
Q9504 UN2213-X DIGI TRANSISTOR
Q9505 UN2212-X DIGI TRANSISTOR
Q9506 UN2212-X DIGI TRANSISTOR
Q9507 2SB1188/QR/-W TRANSISTOR
Q9508 UN2212-X DIGI TRANSISTOR
Q9551 2SC1623A/5-6/-X TRANSISTOR
Q9555 2SB1188/QR/-W TRANSISTOR
Q9556 UN2212-X DIGI TRANSISTOR
Q9557 UN2213-X DIGI TRANSISTOR
Q9558 UN2213-X DIGI TRANSISTOR
Q9602 UN2212-X DIGI TRANSISTOR
Q9603 UN2212-X DIGI TRANSISTOR
 D9001 TS25P05G-C2 BRIDGE DIODE
D9002 1SS355W-X DIODE
D9003 1SS355W-X DIODE
D9203 EG01C-T2 SI DIODE
D9204 SSPX-66-W DIODE
D9206 EC21QS10-X SB DIODE
D9212 EM1A-T2 SI DIODE
D9213 EM1A-T2 SI DIODE
D9214 EM1A-T2 SI DIODE
D9215 MA8330/M/-X Z DIODE
D9216 MA8150/M/-X Z DIODE
D9217 MA8150/M/-X Z DIODE
D9218 SSPX-66-W DIODE
D9501 YG972S6R SI DIODE
D9502 RF101L2S-X DIODE
D9503 1SS355W-X DIODE
D9504 1SS355W-X DIODE
D9505 RF101L2S-X DIODE
D9506 1SS355W-X DIODE
D9507 MA8100/M/-X Z DIODE
D9508 1SS355W-X DIODE
D9552 SD883-04-X SB DIODE
D9553 PTZ27B-X Z DIODE
D9554 PTZ27B-X Z DIODE
D9555 SD883-04-X SB DIODE
D9556 UDZS3.9B-X Z DIODE
D9561 1SS355W-X DIODE
D9601 FCHS20A08 SB DIODE
D9602 FCHS20A08 SB DIODE
D9603 FCHS20A08 SB DIODE
D9604 FCHS20A08 SB DIODE
D9651 D1FL20U-X SI DIODE
D9652 D1FL20U-X SI DIODE
D9653 MTZJ16B-T2 Z DIODE
D9654 MTZJ16B-T2 Z DIODE
D9702 EC30HA04-X SB DIODE
D9752 EC30HA04-X SB DIODE
 C9001 QFZ9084-474 MPP CAPACITOR 0.47uF
 C9002 QFZ9084-474 MPP CAPACITOR 0.47uF
 C9003 QCZ9071-331 C CAPACITOR 330pF AC400V K
 C9004 QCZ9071-331 C CAPACITOR 330pF AC400V K
 C9006 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9007 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9008 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9009 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9010 QCZ9071-681 C CAPACITOR 680pF AC400V M
C9204 QEZ0709-106 E CAPACITOR 10uF 450V M
C9205 QCB32HK-103 C CAPACITOR 0.01uF 500V K
C9206 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C9207 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9208 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9210 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9211 QECR1AM-128Z E CAPACITOR 1200uF 10V M
C9212 QEHR1AM-477Z E CAPACITOR 470uF 10V M
C9219 QEHR1VM-107Z E CAPACITOR 100uF 35V M
C9501 QEZ0739-337 E CAPACITOR 330uF
C9502 QCZ0340-331 C CAPACITOR 330pF 2kV K
C9503 QFZ0231-225 MM CAPACITOR 2.2uF
C9504 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9505 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9506 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C9507 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C9508 QEHR1VM-476Z E CAPACITOR 47uF 35V M
C9509 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9510 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9511 QEHR1HM-107Z E CAPACITOR 100uF 50V M
C9512 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9551 QFZ0230-563 MPP CAPACITOR 0.056uF
C9553 NCB31HK-821X C CAPACITOR 820pF 50V K
C9554 NCB31HK-182X C CAPACITOR 1800pF 50V K
C9555 NCB31HK-331X C CAPACITOR 330pF 50V K
C9556 QEHR1CM-107Z E CAPACITOR 100uF 16V M
C9557 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9558 NCB31CK-105X C CAPACITOR 1uF 16V K
C9559 NCB31HK-102X C CAPACITOR 1000pF 50V K
