1-24 (No.YA708<Rev.002>)
4.4.6 VSM PRESET MODE
This mode is used to adjust the VSM.
4.4.6.1 HOW TO ENTER THE VSM PRESET MODE
When the SERVICE MENU SCREEN of SERVICE MODE is
displayed, press [6] key to enter the VSM PRESET MODE.
4.4.6.2 DESCRIPTION OF STATUS DISPLAY
(1) SETTING ITEM NAME
Setting item name are displayed.
(2) PICTURE MODE
The picture mode name are dispalayed.
(3) SETTING VALUE (DATA)
The setting values are displayed. The setting value to be
displayed are listed below.
4.5 INITIAL SETTING VALUES IN THE SERVICE MODE
• Perform fine-tuning based on the "initial values" using the remote control when in the Service mode.
• The "initial values" serve only as an indication rough standard and therefore the values with which optimal display can be achieved
may be different from the default values.
• <S004> to <S009> are the off set values.
4.5.1 ADJUSTMENT MODE
Note: " ∗ " Adjustable range is -256 ~ 00 only and one colour(R or G or B) should be "00"
SERVICE MODE SCREEN
Press [6] key
(1)SETTING ITEM
(2)PICTURE MODE
(3)
SETTING VALUE (DATA)
VSM PRESET MODE SCREEN
SERVICE MENU Ver.XXX
1. ADJUST
2. SELF CHECK
3. I2C STOP
VSM PRESET
Sof Bri Sta Gam
Back Light XX XX XX XX
Contrast XX XX XX XX
Bright XX XX XX XX
Sharp XX XX XX XX
Colour XX XX XX XX
Tint XX XX XX XX
Soft Bright Standard
Game mode
Back Light 16 32 24 16
Contrast 16 18 16 16
Bright 16 16 16 16
Sharp 16201616
Colour 16 16 16 16
Tint 16 16 16 16
Item No. Item name Variable range Setting value
S001 R DRIVE MID 0000 - 0255 ∗
S002 G DRIVE MID 0000 - 0255 ∗
S003 B DRIVE MID 0000 - 0255 ∗
S004 R DRIVE COOL 0000 - 0255 -142
S005 G DRIVE COOL 0000 - 0255 -47
S006 B DRIVE COOL 0000 - 0255 +30
S007 R DRIVE WARM 0000 - 0255 +50
S008 G DRIVE WARM 0000 - 0255 +10
S009 B DRIVE WARM 0000 - 0255 -138
To Next Page
