JVC LVT0853-009B Service Manual

3-1
VS-DT9R/VS-DT6R
PARTS LIST
* All printed circuit boards and its assemblies are not available as service parts.
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
CD mechanism assembly and parts list (Block No.MB)
Electrical parts list (Block No.01~05)
Packing materials and accessories parts list VS-DT9R(Block No.M3,M5)
VS-DT6R(Block No.M4,M6)
[ VS-DT9R ]
[ VS-DT6R ]
3- 3
3- 5
3- 8
3-18
3-20
Area suffix
B ------------------------------- U.K.
E ----------- Continental Europe
EN ------------ Northern Europe
EV -------------- Eastern Europe

JVC LVT0853-009B Specifications

General

Brand	JVC
Model	LVT0853-009B
Category	Stereo System
Language	English
