1-2 (No.MB398)
SPECIFICATION
*1 Measured on AC 110 V, 127 V, 220 V, and 240 V
*2 Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency -32 kHz, 44.1 kHz, 48 kHz)
Designs and Specifications are subject to change without notice.
Amplifier
Output Power At Stereo operation Front channels 100 W*1 per channel, min. RMS, driven into 8
Ω,
at 1 kHz with no more than 0.8% total harmonic
distortion (IEC268-3/DIN).
At Surround operation Front channels 100 W per channel, min. RMS, driven into 8
Ω, at
1 kHz with no more than 0.8% total harmonic dis-
tortion.
Center channel 100 W, min. RMS, driven into 8
Ω, at 1 kHz with
no more than 0.8% total harmonic distortion.
Surround channels 100 W per channel, min. RMS, driven into 8
Ω, at
1 kHz with no more than 0.8% total harmonic dis-
tortion.
Audio Audio Input Sensitivity/Impedance
(1 kHz)
CD, TAPE/CDR, VCR, TV SOUND, DVD 220 mV/47 k
Ω
Audio Input (DIGITAL IN)*2 Coaxial DIGITAL 1 (DVD):0.5 V(p-p)/75 Ω
Optical DIGITAL 2 (CD), DIGITAL 3 (TV):-21 dBm to -15
dBm (660 nm ±30 nm)
Recording Output Level TAPE/CDR, VCR 220 mV
Signal-to-Noise Ratio ('66 IHF/DIN) CD, TAPE/CDR, VCR, TV SOUND, DVD 87 dB/62 dB
Frequency Response (8
Ω) CD, TAPE/CDR, VCR, TV SOUND, DVD 20 Hz to 50 kHz (+1 dB, -3 dB)
Bass Boost +3 dB ±1 dB at 100 Hz
Equalization (5 bands) 63 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz ±8 dB (in 2 dB steps)
Video Video Input Sensitivity/Impedance Composite video:DVD, VCR 1 V(p-p)/75
Ω
S-video:DVD, VCR (Y: luminance):1 V(p-p)/75 Ω
(C: chrominance, burst):0.286 V(p-p)/75 Ω
Component:DVD, VCR (Y: luminance):1 V(p-p)/75 Ω
(PB, PR):0.7 V(p-p)/75 Ω
Video Output Level Composite video:VCR, MONITOR OUT 1 V(p-p)/75 Ω
S-video:VCR, MONITOR OUT (Y: luminance):1 V(p-p)/75 Ω
(C: chrominance, burst):0.286 V(p-p)/75 Ω
Component:MONITOR OUT (Y: luminance):1 V(p-p)/75 Ω
(PB, PR):0.7 V(p-p)/75 Ω
Synchronization Negative
Signal-to-Noise Ratio 45 dB
FM tuner (IHF)
Tuning Range 87.50 MHz to 108.00 MHz
Usable Sensitivity Monaural 12.8 dBf (1.2
µV/75 Ω)
50 dB Quieting
Sensitivity
Monaural 16.0 dBf (1.7
µV/75 Ω)
Stereo 37.5 dBf (20.5
µV/75 Ω)
Stereo Separation at OUT (REC) 35 dB at 1 kHz
AM tuner
Tuning Range 531 kHz to 1 602 kHz (at 9 kHz intervals)
530 kHz to 1 600 kHz (at 10 kHz intervals)
General
Power Requirements AC 110 V/127 V/220 V/230 V - 240 V , adjustable
with the voltage selector, 50 Hz/60 Hz
Power Consumption 200 W (at operation)
2 W (in standby mode)
Dimensions (W
× H × D) 435 mm × 146.5 mm × 409.5 mm
Mass 9.8 kg
