JVC LVT1140-004A Service Manual

3-7
Front board
Block No. [0][2]
R442 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R443 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R444 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R445 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R446 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
 R449 QRJ146J-271X UNF C RESISTOR 270 Ω 1/4W J
 R450 QRJ146J-271X UNF C RESISTOR 270 Ω 1/4W J
R451 QRE141J-471Y C RESISTOR 470 Ω 1/4W J
R452 QRE141J-471Y C RESISTOR 470 Ω 1/4W J
R453 QRE141J-471Y C RESISTOR 470 Ω 1/4W J
R454 QRE141J-471Y C RESISTOR 470 Ω 1/4W J
R455 QRE141J-471Y C RESISTOR 470 Ω 1/4W J
R456 QRE141J-471Y C RESISTOR 470 Ω 1/4W J
 R458 QRJ146J-271X UNF C RESISTOR 270 Ω 1/4W J
 R459 QRJ146J-271X UNF C RESISTOR 270 Ω 1/4W J
R461 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R462 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R463 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R464 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R551 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R552 QRE141J-750Y C RESISTOR 75
Ω 1/4W J
R555 QRE141J-750Y C RESISTOR 75
Ω 1/4W J
R556 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R557 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R558 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R559 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R560 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R561 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R562 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R563 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R564 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R565 QRE141J-561Y C RESISTOR 560 Ω 1/4W J
R566 QRE141J-241Y C RESISTOR 240 Ω 1/4W J
R571 QRE141J-561Y C RESISTOR 560 Ω 1/4W J
R572 QRE141J-241Y C RESISTOR 240 Ω 1/4W J
R573 QRE141J-751Y C RESISTOR 750 Ω 1/4W J
R574 QRE141J-751Y C RESISTOR 750 Ω 1/4W J
 R581 QRJ146J-6R8X UNF C RESISTOR 6.8 Ω 1/4W J
 R1301 QRL027J-332 OMF RESISTOR 3.3k Ω 2W J
 R1302 QRZ9005-100X FUSI RESISTOR 10 Ω
 R1303 QRJ146J-332X UNF C RESISTOR 3.3k Ω 1/4W J
R1304 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R1305 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R1306 QRE141J-823Y C RESISTOR 82k Ω 1/4W J
R1307 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R1308 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R1309 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R1310 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R1311 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R1312 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
 R1313 QRZ9005-100X FUSI RESISTOR 10 Ω
 R1314 QRJ146J-103X UNF C RESISTOR 10k Ω 1/4W J
 R1315 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
 R1316 QRJ146J-102X UNF C RESISTOR 1k Ω 1/4W J
 R1317 QRJ146J-223X UNF C RESISTOR 22k Ω 1/4W J
R1318 QRE141J-223Y C RESISTOR 22k
Ω 1/4W J
R1319 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
 R1352 QRJ146J-680X UNF C RESISTOR 68 Ω 1/4W J
 R1353 QRJ146J-680X UNF C RESISTOR 68 Ω 1/4W J
 R1354 QRJ146J-680X UNF C RESISTOR 68 Ω 1/4W J
 R1355 QRJ146J-392X UNF C RESISTOR 3.9k Ω 1/4W J
R1356 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R1357 QRE141J-223Y C RESISTOR 22k
Ω 1/4W J
R1358 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R1359 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R1360 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R1361 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R1362 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R1363 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R1364 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R1365 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R1366 QRE141J-223Y C RESISTOR 22k
Ω 1/4W J
R1367 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
 R1370 QRJ146J-2R7X UNF C RESISTOR 2.7 Ω 1/4W J
 R1371 QRJ146J-2R7X UNF C RESISTOR 2.7 Ω 1/4W J
 R1372 QRJ146J-2R7X UNF C RESISTOR 2.7 Ω 1/4W J
 R1373 QRJ146J-2R7X UNF C RESISTOR 2.7 Ω 1/4W J
 R1374 QRJ146J-2R7X UNF C RESISTOR 2.7 Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
L1351 QQLZ005-R45 COIL 0.45uH
L1352 QQLZ005-R45 COIL 0.45uH
L1353 QQLZ005-R45 COIL 0.45uH
L1354 QQLZ005-R45 COIL 0.45uH
L1355 QQLZ005-R45 COIL 0.45uH
CN311 QGB2510J1-14 CONNECTOR B-B (1-14)
CN312 QGB2510J1-14 CONNECTOR B-B (1-14)
CN321 QGB2510J1-14 CONNECTOR B-B (1-14)
CN331 QGB2510J1-14 CONNECTOR B-B (1-14)
CN332 QGB2510J1-14 CONNECTOR B-B (1-14)
CN351 QJK012-032403 SKT WIRE ASSY
CN371 QJP001-031201 SHI CR C-B WIRE
CN372 QJP002-021201 SHI CR C-B WIRE
CN373 QJP001-031201 SHI CR C-B WIRE
CN401 QGB2510K1-14 CONNECTOR B-B (1-14)
CN451 QGB2510K1-11 CONNECTOR B-B (1-11)
CN511 QGD2503F1-03 CONNECTOR (1-3)
CN551 QGB2510K1-08 CONNECTOR B-B (1-8)
EP301 QNZ0136-001Z EARTH PLATE
FW301 QUM215-27Z4Z4 PARA RIBON WIRE
FW302 QUM216-27Z4Z4 PARA RIBON WIRE
FW303 QUM215-28DGZ4 PARA RIBON WIRE
FW341 QUM215-20DGZ4 SOCKET
J402 QNN0168-001 PIN JACK
J403 QNN0168-001 PIN JACK
J404 QNN0389-001 PIN JACK
J405 QNN0388-001 PIN JACK
J406 QNN0060-001 PIN JACK
J551 QND0091-001 S JACK
J552 QND0091-001 S JACK
 RY302 QSK0109-001 RELAY
 RY303 QSK0109-001 RELAY
 RY304 QSK0109-001 RELAY
ST304 QNB0103-002 SPK TERMINAL
ST305 QNB0001-002 SPK TERMINAL
 Symbol No. Part No. Part Name Description Local
IC421 NJM4565M-WE IC
IC422 NJM4565M-WE IC
IC423 TC9162AF-X IC
IC427 NJM4565M-WE IC
IC428 BD3814FV-X IC
IC581 MM1504XN-X IC
IC582 MM1506XN-X IC
IC583 MM1506XN-X IC
IC701 MN101C35DMW IC(1-TIME)
IC702 IC-PST9139-T IC
IC703 GP1UM281XKVF IR DETECT UNIT
Q701 UN2214-X TRANSISTOR
Q702 UN2215-X TRANSISTOR
Q703 KRC109S-X TRANSISTOR
Q704 UN2214-X TRANSISTOR
Q707 UN2214-X TRANSISTOR
Q708 UN2214-X TRANSISTOR
Q709 UN2214-X TRANSISTOR
Q711 UN2113-X DIGI TRANSISTOR
 Q1401 KTA1046/Y/ TRANSISTOR
 Q1402 KTC2026/Y/ TRANSISTOR
 Q1403 KTC2026/Y/ TRANSISTOR
 Q1404 KTC2026/Y/ TRANSISTOR
 Q1405 KTC2026/Y/ TRANSISTOR
 Q1406 KTC3203/OY/-T TRANSISTOR
 Q1407 KTC3203/OY/-T TRANSISTOR
 Q1408 KTA1271/OY/-T TRANSISTOR
Q1409 2SK301/PQ/-T TRANSISTOR
Q1410 2SK301/PQ/-T TRANSISTOR
Q1411 2SK301/PQ/-T TRANSISTOR
 Symbol No. Part No. Part Name Description Local
