JVC MX-G70 User Manual

MX-G70
3-4
Item Parts number Parts name Area
A
Parts list (General assembly)
Q'ty Description
Block No. M1MM
1 GV10057-001A FRONT PANEL 1
2 E75896-001 FELT SPACER 2
3 GV40077-002A JVC BADGE 1
4 GV40136-001A STBY.INDICATOR 1
5 GV30154-001A CD BUTTON 1
6 GV20104-002A CD EJECT BUTTON 1
7 GV30137-001A POWER BUTTON 1
8 GV30177-001A CONTROL BUTTON 1
9 GV30139-001A REMOTO LENS 1
10 QYSDSF2608Z SCREW 12 ON VOLUME BRD.
11 QYSDSF2608Z SCREW 3 ON CD BRD.
12 QYSDSF2608Z SCREW 7 ON MICOM BRD.
13 QYSDSF2608Z SCREW 5 ON SOURCE BRD.
14 GV30129-001A STAY BRACKET 1
15 GV10060-007A ORNAMENT 1
16 QYSDSF2608Z SCREW 5 STY.BRKT.+F.PNL
17 FMYH4004-001 PLASTIC RIVET 1 M.BRD.+ STY BRK
18 GV20103-001A SUB. PANEL 1
19 GV30138-001A FRONT BUTTON 1
20 GV40185-002A COVER SHEET 1
21 GV30211-004A C.HOLDER ASSY
(
L
)
1
22 GV30212-004A C.HOLDER ASSY
(
R
)
1
23 GV20099-002A EJECT BUTTON
(
A
)
1
24 GV20100-002A EJECT BUTTON
(
B
)
1
25 FMKW4009-002 HOLDER SPRING
(
A
)
1
26 FMKW4010-002 HOLDER SPRING
(
B
)
1
27 FMKW4011-001 SPRING 1 FOR EJECT LEVER
28 FMKS3002-003 EJECT LEVER
(
A
)
1
29 FMKS3003-003 EJECT LEVER
(
B
)
1
30 GV40034-001A DAMPER ASSY 2
31 VKY4180-401 CASSETTE SPRING 4
32 --------------- CASSETTE MECHA 1
33 FMKL4012-004 EJECT SAFETY
(
A
)
1
34 FMKL4013-001 EJECT SAFETY
(
B
)
1
35 FMKW4007-001 SPRING
(
A
)
1 EJECT SAFETY
(
A
)
36 FMKW4008-001 SPRING
(
B
)
1 EJECT SAFETY
(
B
)
37 GV20094-001A HOLDER BRACKET 1
38 QYSBSG3010Z T.SCREW 2 F.P.TO H.BRKT.
39 QYSBSG3010Z T.SCREW 2 F.P.TO CHASS.BS
40 QYSBSG3010Z T.SCREW 3 MECHA & H.BRKT.
41 QYSBSF3012Z SCREW 4 MECHA & F.PANEL
42 GV30124-001A TRANS SHIELD 1
43 E3400-431 SPACER 1 STICK AT SLC MO
44 --------------- CD CHANGER MECHA 1
45 --------------- CD MECHA 1
46 LV40761-003A INSULATOR 2
47 LV40761-003A INSULATOR 2
48 VKS3703-00L CLAMPER ASS'Y 1
Item Parts number Parts name Area
A
Parts list (General assembly)
Q'ty Description
Block No. M1MM
49 QYSPST2606Z SCREW 1
50 VKW5187-001 ROD 1
51 QUQ610-1509AJ FFC WIRE 1
52 VDM1001-M002AV WIRE & TUBE 1
53 QYSBSF2608Z T.SCREW 4
54 VYSA1R2-033 SPACER 1 FOR VDM1001-M00
55 E309662-001SM DISC STOPPER 1
56 QYSBSF3008Z SCREW 1 FOR DISC STOPPE
57 QYSBSF3008Z SCREW 1 FOR LOD STOPPER
58 GV40189-001A FAN BRACKET 1
59 QYSBSF3010Z SCREW 2 FAN BRKT/CD MEC
60 QYSBSG3035Z T.SCREW 2 FAN TO FAN BRAC
61 FMYH4004-001 PLASTIC RIVET 1 TUNER BRD.+ FMC
62 GV10061-001A CHASSIS BASE 1
63 E75896-006 FELT SPACER 2 CHASS BASE FOOT
64 GV30191-002A HEAT SINK 1
65 GV40178-001A HEAT SINK BRKT. 2
66 QYSBSG3014E T.SCREW 4 FOR POWER IC
67 GV40143-001A LEAF SPRING 1
68 QYSBSG3014E T.SCREW 2 FOR LEAF SPRING
69 QYSDSTL4008Z SPECIAL SCREW 4 FOR TRANS/CH.BS
70 QYSBSGG3008E T.SCREW 2 FMH BRD./CH.BS
71 QYSBSGG3008E T.SCREW 1 FMC BRD./CH.BS
72 QZW0033-001 STRAIN RELIEF 1
73 QMF51U1-5R0-J8 FUSE
A
1 F001
74 QMF51U1-6R0-J8 FUSE
A
1 F101
75 QMF51U1-6R0-J8 FUSE
A
1 F102
76 VKZ4001-110S WIRE HOLDER 1
77 QQT0319-001 TRANSFORMER
A
1 T001
78 QUQ110-1908BJ FFC WIRE 1 FMC TO VC3
79 QUQ412-0911DJ CARD WIRE 1 FMC TO TUNER
80 QUQ412-1710CJ FFC WIRE 1 FMB TO FMC
(
1
)
81 QUQ412-1710CJ FFC WIRE 1 FMB TO FMC
(
2
)
82 QUQ412-1020CJ FFC WIRE 1 FMC TO SLC
83 QUQ412-0915CJ FFC WIRE 1 FMB TO SLC
84 QUQ412-2210CJ CARD WIRE 1 FMB TO SW
85 QMPD380-200-JN POWER CORD
A
1
86 GV10062-001A REAR PANEL 1
87 GV10063-002A REAR COVER 1
88 QYSBSG3010Z T.SCREW 2 C3 MECHA/S.BRKT
89 QAR0177-001 FAN 1 SUPPLIER NIDEC
90 QYSBSGY3008E SPECIAL SCREW 1 REAR PNL/CHAS.B
91 QYSBSGY3008E SPECIAL SCREW 4 REAR PNL/ H.SIN
92 QYSBSGY3008E SPECIAL SCREW 1 REAR PNL/ AUX
93 QYSBSGY3008E SPECIAL SCREW 2 C3/ REAR PANEL
94 QYSBSGY3008E SPECIAL SCREW 2 SPK/ REAR PANEL
95 QYSBSGY3008E SPECIAL SCREW 2 TUNER/REAR PANE
96 QYSBSGY3008E SPECIAL SCREW 1 REAR CVR/R.PNL
