MX-G70
3-5
Item Parts number Parts name Area
A
Parts list (General assembly)
Q'ty Description
Block No. M1MM
97 QYSBSGY3008E SPECIAL SCREW 1 OPTICAL/R.PANEL
98 GV10055-001A/S/ METAL COVER 1
99 QYSDSG3006M T.SCREW 2 M.COVER/C.BASE
100 QYSBSGY3008E SPECIAL SCREW 6 M.COVER/R.PANEL
101 GV20106-005A CD FITTING 1 DISC 1
102 GV20107-005A CD FITTING 1 DISC 2
103 GV20108-005A CD FITTING 1 DISC 3
104 GV30179-001A VOLUME KNOB ASS 1
105 GV30180-001A SUB.WFR.KB.ASSY 1
106 GV30181-001A SND.MODE KB.ASS 1
107 GV30182-001A CD.FWD.KB.ASSY 1
108 GV20098-001A WINDOW SCREEN 1
109 GV40181-001A MIRROR SHEET 1
110 GV30155-002A VOLUME RING 1
111 GV30151-002A SUB.WOOFER RING 1
112 GV30152-002A SOUND MODE RING 1
113 GV30153-002A CD FORWARD RING 1
114 GV40186-001A NUT 1 FOR VOLUME ENCO
115 GV30141-001A DISPLAY HOLDER 1
116 E3400-439 FELT SPACER 2
