JVC MX-G880V

4-17
MX-G950V/MX-G880V
MX-G850V/MX-G750V
Item
Parts number Parts name Ar
e
a
Remarks
A
R 794 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 795 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 796 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 797 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R 798 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 908 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
S 901 QSW0825-001Z TACT SWITCH
S 902 QSW0825-001Z TACT SWITCH
Electrical parts list (Power board)
Block No. 01
