MX-G950V/MX-G880V

MX-G850V/MX-G750V

4-18

Item

Parts number Parts name Ar

Remarks

C 002 QFVH1HJ-104 MF CAPACITOR .10MF 5% 50V

C 401 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 402 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V

C 403 FQCF31HP-103Z C CAPACITOR

C 404 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 419 QDXB1CM-222Y C CAPACITOR

C 426 QDVB1EZ-223Y C CAPACITOR

C 427 EETC1EM-106ZJC E CAPACITOR

C 433 FQCF31HP-103Z C CAPACITOR

C 436 EETC1AM-107ZJC E CAPACITOR

C 437 EETC1EM-106ZJC E CAPACITOR

C 438 QDYB1CM-103Y C CAPACITOR

C 439 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 440 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 441 QTE1V06-106Z E CAPACITOR

C 442 QTE1V06-106Z E CAPACITOR

C 443 EETC1HM-225ZJC E CAPACITOR

C 444 EETC1HM-225ZJC E CAPACITOR

C 445 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 446 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 447 QETN1CM-106Z E CAPACITOR 10MF 20% 16V

C 448 QETN1CM-106Z E CAPACITOR 10MF 20% 16V

C 449 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 450 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 453 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V

C 454 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V

C 455 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V

C 456 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V

C 457 QFLC1HJ-223Z M CAPACITOR .022MF 5% 50V

C 458 QFLC1HJ-223Z M CAPACITOR .022MF 5% 50V

C 459 QFLC1HJ-183Z M CAPACITOR .018MF 5% 50V

C 460 QFLC1HJ-183Z M CAPACITOR .018MF 5% 50V

C 461 QFG32AJ-682Z PP CAPACITOR 6800PF 5% 100V

C 462 QFG32AJ-682Z PP CAPACITOR 6800PF 5% 100V

C 466 QTE1C06-476Z E CAPACITOR

C 467 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 468 EETC1EM-226ZJC E CAPACITOR

C 469 QFLC1HJ-683Z M CAPACITOR .068MF 5% 50V

C 470 QFVJ1HJ-274Z MF CAPACITOR .27MF 5% 50V

C 471 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 472 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 473 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 474 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 475 EETC1HM-105ZJC E CAPACITOR

C 476 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V

C 481 QFG32AJ-223Z PP CAPACITOR .022MF 5% 100V

C 482 QFG32AJ-223Z PP CAPACITOR .022MF 5% 100V

C 483 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 484 QFLM1HJ-223Z M CAPACITOR .022MF 5% 50V

C 485 QTE1V06-106Z E CAPACITOR

C 486 QTE1V06-106Z E CAPACITOR

C 487 EETC1AM-107ZJC E CAPACITOR

C 488 EETC1HM-105ZJC E CAPACITOR

C 489 EETC1AM-107ZJC E CAPACITOR

C 501 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 502 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 503 QFVJ1HJ-224Z MF CAPACITOR .22MF 5% 50V

C 504 QFLC1HJ-822Z M CAPACITOR 8200PF 5% 50V

C 505 QFVJ1HJ-274Z MF CAPACITOR .27MF 5% 50V

C 507 QFLC1HJ-153Z M CAPACITOR .015MF 5% 50V

C 508 QFLC1HJ-273Z M CAPACITOR .027MF 5% 50V

C 509 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 510 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 514 QFLC1HJ-823Z M CAPACITOR .082MF 5% 50V

C 526 EETC1AM-107ZJC E CAPACITOR

C 527 QFLC1HJ-183Z M CAPACITOR .018MF 5% 50V

C 528 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V

C 530 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V

C 531 QFLC1HJ-683Z M CAPACITOR .068MF 5% 50V

C 532 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 534 QTE1C06-476Z E CAPACITOR

C 535 EETC1AM-107ZJC E CAPACITOR

C 556 QETN1EM-106Z E CAPACITOR 10MF 20% 25V

C 571 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 575 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V

C 576 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 577 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 578 EETC1HM-105ZJC E CAPACITOR

C 585 EETC1HM-105ZJC E CAPACITOR

C 586 QDXB1CM-182Y C CAPACITOR

C 587 QCSB1HJ-330Y C CAPACITOR 33PF 5% 50V

C 588 QDGB1HK-681Y C CAPACITOR

C 589 QFLC1HJ-153Z M CAPACITOR .015MF 5% 50V

C 593 FQCS31HJ-470Z C CAPACITOR

C 594 QETN1AM-477Z E CAPACITOR 470MF 20% 10V

C 596 QDYB1CM-103Y C CAPACITOR

C 599 QETN0JM-108Z E CAPACITOR 1000MF 20% 6.3V

C 980 QDVB1EZ-223Y C CAPACITOR

C 981 QCZ0202-155Z ML C CAPACITOR 1.5MF

C 995 EETC1AM-107ZJC E CAPACITOR

C 996 QCSB1HJ-100Y C CAPACITOR 10PF 5% 50V

C 997 QCSB1HJ-100Y C CAPACITOR 10PF 5% 50V

C 998 QDXB1CM-472Y C CAPACITOR

C 999 QDXB1CM-472Y C CAPACITOR

CN 11 QGF1205F1-09 CONNECTOR

CN208 WJK0114-002A E-SI C WIRE C-B

CN209 WJK0071-002A CONN.WIRE ASSY

CN211 QGB2510K2-11 CONNECTOR

CN212 QGB2510K2-10 CONNECTOR

CN213 QGB2510K2-04 CONNECTOR

CN214 QJK015-071214 CONN.WIRE ASSY

CN218 QGA7901F1-03 CONNECTOR

CN219 QGA7901C1-04 CONNECTOR

CN220 QGD2504C1-03Z SOCKET

CN250 QGA7901C1-02 CONNECTOR

CN315 QGF1205C1-10 CONNECTOR

CN504 QGF1016F3-15 CONNECTOR

CN661 QGF1016F3-19 CONNECTOR

CN870 QGF1205C1-17 CONNECTOR

CN871 QGF1205C1-17 CONNECTOR

C1201 QETN1AM-227Z E CAPACITOR 220MF 20% 10V

C1202 QFLC1HJ-823Z M CAPACITOR .082MF 5% 50V

C1228 EETC1AM-107ZJC E CAPACITOR

D 411 1SS119-041-T2 SI DIODE

D 412 1SS119-041-T2 SI DIODE

D 426 DZ5.1BSB-T2 ZENER DIODE

D 431 DZ3.9BSB-T2 ZENER DIODE

D 432 DZ3.9BSB-T2 ZENER DIODE

D 434 DZ5.1BSB-T2 ZENER DIODE

D 501 1SS119-041-T2 SI DIODE

D 502 1SS119-041-T2 SI DIODE

D 571 1SS119-041-T2 SI DIODE

D 572 1SS119-041-T2 SI DIODE

D 585 1SS119-041-T2 SI DIODE

D 586 DZ6.8BSC-T2 ZENER DIODE

D 587 DZ6.8BSC-T2 ZENER DIODE

Electrical parts list (Input board)

Block No. 02

Item

Parts number Parts name Ar

Remarks
