JVC MX-G880V - Electrical parts list (Power board)

MX-G950V/MX-G880V
MX-G850V/MX-G750V
5-14
Item
Parts number Parts name Ar
e
a
Remarks
A
Electrical parts list (Power board)
Block No. 01
Item
Parts number Parts name Ar
e
a
Remarks
A
C 201 QFZ0212-104Z MM CAPACITOR .10MF
C 202 QFZ0212-104Z MM CAPACITOR .10MF
C 203 QFZ0212-104Z MM CAPACITOR .10MF
C 204 EETB1XM-478JC E CAPACITOR
C 205 EETB1XM-478JC E CAPACITOR
C 211 QFLC1HJ-823Z M CAPACITOR .082MF 5% 50V
C 212 QFLC1HJ-823Z M CAPACITOR .082MF 5% 50V
C 213 QFLC1HJ-823Z M CAPACITOR .082MF 5% 50V
C 214 EETB1VM-228JC E CAPACITOR
C 215 EETB1VM-228JC E CAPACITOR
C 216 QETN1VM-107Z E CAPACITOR 100MF 20% 35V
C 217 QETN1JM-476Z E CAPACITOR 47MF 20% 63V
C 218 EETC1HM-226ZJC E CAPACITOR
C 219 QDYB1CM-103Y C CAPACITOR
C 220 EETC1HM-476ZJC E CAPACITOR
C 221 EETC1HM-476ZJC E CAPACITOR
C 222 EETC1HM-476ZJC E CAPACITOR
C 253 EETB1EM-688JC E CAPACITOR
C 280 EETC1HM-224ZJC E CAPACITOR
C 372 EETC1HM-226ZJC E CAPACITOR
C 373 QDYB1CM-103Y C CAPACITOR
C 374 EETC1HM-226ZJC E CAPACITOR
C 683 QFLC1HJ-823Z M CAPACITOR .082MF 5% 50V
C 703 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 704 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 705 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 706 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 707 QETN1JM-476Z E CAPACITOR 47MF 20% 63V
C 708 QETN1JM-476Z E CAPACITOR 47MF 20% 63V
C 709 QCSB1HK-4R7Y C CAPACITOR 4.7PF 10% 50V
C 710 QCSB1HK-4R7Y C CAPACITOR 4.7PF 10% 50V
C 711 QFZ0212-104Z MM CAPACITOR .10MF
C 712 QFZ0212-104Z MM CAPACITOR .10MF
C 713 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 714 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 715 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 716 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 721 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 722 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 723 EETC1AM-107ZJC E CAPACITOR
C 726 EETC1EM-106ZJC E CAPACITOR
C 729 EETC1CM-476ZJC E CAPACITOR
C 730 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C 731 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C 739 EETC1HM-105ZJC E CAPACITOR
C 790 EETC1EM-476ZJC E CAPACITOR
C 901 QDYB1CM-103Y C CAPACITOR
C 902 QDYB1CM-103Y C CAPACITOR
CN201 QGB2510J1-11 CONNECTOR
CN202 QGB2510J1-10 CONNECTOR
CN203 QGB2510J1-04 CONNECTOR
CN204 QGA3901C1-07 CONNECTOR
CN205 QGB2510J1-14 CONNECTOR
CN206 QGB2510J1-12 CONNECTOR
CN207 QGB2510J1-06 CONNECTOR
CN215 QGB2510K2-14 CONNECTOR
CN703 QGD2504C1-03Z SOCKET
CN704 QGD2504C1-03Z SOCKET
CN705 QGA2501C1-02 2P CONNECTOR
CN706 QGD2504C1-03Z SOCKET
D 201 1N5402M-20 DIODE
A
D 202 1N5402M-20 DIODE
A
D 203 1N5402M-20 DIODE
A
D 204 1N5402M-20 DIODE
A
D 211 1N5402M-20 DIODE
A
D 212 1N5402M-20 DIODE
A
D 213 1N5402M-20 DIODE
A
D 214 1N5402M-20 DIODE
A
D 217 1N4003S-T5 SI DIODE
A
D 218 1N4003S-T5 SI DIODE
A
D 219 DZ33BSC-T2 ZENER DIODE
D 220 DZ9.1BSB-T2 ZENER DIODE
D 227 1N4003S-T5 SI DIODE
A
D 233 2A02-M DIODE
A
D 234 2A02-M DIODE
A
D 280 DZ2.4BSB-T2 ZENER DIODE
D 369 DZ10BSC-T2 ZENER DIODE
D 370 DZ11BSC-T2 ZENER DIODE
D 703 DZ15BSC-T2 ZENER DIODE
D 704 DZ15BSC-T2 ZENER DIODE
D 719 1SS119-041-T2 SI DIODE
D 720 1SS119-041-T2 SI DIODE
D 723 DZ36BSA-T2 ZENER DIODE
D 724 DZ36BSA-T2 ZENER DIODE
D 726 1SS119-041-T2 SI DIODE
D 728 1SS119-041-T2 SI DIODE
D 790 1SS119-041-T2 SI DIODE
EP201 QNZ0136-001Z EARTH PLATE
EP202 QNZ0136-001Z EARTH PLATE
EP710 GV40327-001A IC BOARD HOLDER
FW707 QUM153-09Z4Z4 PARA RIBON WIRE
FW901 QUM027-13DGZ4 PARA RIBON WIRE
IC701 STK412-090 IC
A
JS901 QSW0911-001 ROTARY SWITCH
L 701 QQLZ035-R39 INDUCTOR
L 702 QQLZ035-R39 INDUCTOR
Q
201 2SB740/BC/-T TRANSISTOR
Q
240 2SC2785/FE/-T TRANSISTOR
Q
372 KTA1023/OY/-T TRANSISTOR
Q
373 KRA104M-T D.TRANSISTOR
Q
374 KRC104M-T D.TRANSISTOR
Q
680 2SK301/PQ/-T FET
Q
701 KTA1268/GL/-T TRANSISTOR
Q
702 KTA1268/GL/-T TRANSISTOR
Q
710 2SA965/OY/-T TRANSISTOR
Q
711 KTC3200/GL/-T TRANSISTOR
Q
712 KTA1268/GL/-T TRANSISTOR
Q
713 KTC1027/OY/-T TRANSISTOR
Q
726 2SC2389S/SE/-T TRANSISTOR
Q
727 KTA1268/GL/-T TRANSISTOR
Q
728 2SC2785/FE/-T TRANSISTOR
Q
733 2SC3576-JVC-T TRANSISTOR
Q
734 2SC3576-JVC-T TRANSISTOR
Q
735 2SC3576-JVC-T TRANSISTOR
Q
736 2SC3576-JVC-T TRANSISTOR
Q
737 KRA111M-T D.TRANSISTOR
Q
790 2SC2785/FE/-T TRANSISTOR
Q
791 2SC2785/FE/-T TRANSISTOR
Q
792 KTC3203/OY/-T TRANSISTOR
R 202 QRZ9042-2R2X F RESISTOR
A
2.2 1/4W
R 203 QRE141J-752Y C RESISTOR 7.5K 5% 1/4W
R 204 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 205 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 215 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 216 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 217 QRE141J-273Y C RESISTOR 27K 5% 1/4W
