JVC MX-G880V

5-15
MX-G950V/MX-G880V
MX-G850V/MX-G750V
Item
Parts number Parts name Ar
e
a
Remarks
A
R 218 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 220 QRJ146J-151X UNF C RESISTOR
A
150 5% 1/4W
R 242 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 246 QRJ146J-1R0X UNF C RESISTOR
A
1.0 5% 1/4W
R 247 QRJ146J-1R0X UNF C RESISTOR
A
1.0 5% 1/4W
R 248 QRJ146J-1R0X UNF C RESISTOR
A
1.0 5% 1/4W
R 249 QRJ146J-1R0X UNF C RESISTOR
A
1.0 5% 1/4W
R 281 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 282 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 283 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 284 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 384 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 385 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 389 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 680 QRE141J-105Y C RESISTOR 1.0M 5% 1/4W
R 681 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 682 QRE141J-475Y C RESISTOR 4.7M 5% 1/4W
R 701 QRJ146J-470X UNF C RESISTOR
A
47 5% 1/4W
R 702 QRJ146J-470X UNF C RESISTOR
A
47 5% 1/4W
R 703 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 704 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 705 QRJ146J-821X UNF C RESISTOR
A
820 5% 1/4W
R 706 QRJ146J-821X UNF C RESISTOR
A
820 5% 1/4W
R 707 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 708 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 713 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 714 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 715 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 716 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 717 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 718 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 719 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 720 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 721 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 722 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 723 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 724 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 725 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 726 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 727 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 728 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 729 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 730 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 733 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 734 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 735 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 736 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 739 QRL01DJ-821X OMF RESISTOR
A
820 5% 1W
R 740 QRL01DJ-821X OMF RESISTOR
A
820 5% 1W
R 741 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 742 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 753 QRZ0197-R22 C RESISTOR 1W
R 754 QRZ0197-R22 C RESISTOR 1W
R 761 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 762 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 766 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 768 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 769 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 774 QRJ146J-100X UNF.C.RESISTOR
A
10 5% 1/4W
R 775 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 776 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 777 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 778 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 786 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 787 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 790 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 792 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 793 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 794 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 795 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 796 QRE141J-682Y C RESISTOR
A
6.8K 5% 1/4W
R 797 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R 798 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 908 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
S 901 QSW0825-001Z TACT SWITCH
S 902 QSW0825-001Z TACT SWITCH
Electrical parts list (Power board)
Block No. 01
Item
Parts number Parts name Ar
e
a
Remarks
A
