JVC MX-G880V - Electrical parts list (Input board)

MX-G950V/MX-G880V
MX-G850V/MX-G750V
5-16
Item
Parts number Parts name Ar
e
a
Remarks
A
C 001 QDGB1HK-102Y C CAPACITOR
C 002 QFVH1HJ-104 MF CAPACITOR .10MF 5% 50V
C 401 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 402 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 403 FQCF31HP-103Z C CAPACITOR
C 404 QETN1CM-476Z E CAPACITOR 47MF 20% 16V
C 419 QDXB1CM-222Y C CAPACITOR
C 426 QDVB1EZ-223Y C CAPACITOR
C 427 EETC1EM-106ZJC E CAPACITOR
C 433 FQCF31HP-103Z C CAPACITOR
C 436 QETN1CM-477Z E CAPACITOR 470MF 20% 16V
C 437 EETC1EM-106ZJC E CAPACITOR
C 438 QDYB1CM-103Y C CAPACITOR
C 439 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C 440 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C 441 QTE1V06-106Z E CAPACITOR
C 442 QTE1V06-106Z E CAPACITOR
C 443 EETC1HM-225ZJC E CAPACITOR
C 444 EETC1HM-225ZJC E CAPACITOR
C 445 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C 446 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C 447 QETN1CM-106Z E CAPACITOR 10MF 20% 16V
C 448 QETN1CM-106Z E CAPACITOR 10MF 20% 16V
C 449 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 450 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 453 QFVF1HJ-154Z MF CAPACITOR .15MF 5% 50V
C 454 QFVF1HJ-154Z MF CAPACITOR .15MF 5% 50V
C 455 QFVJ1HJ-274Z MF CAPACITOR .27MF 5% 50V
C 456 QFVJ1HJ-274Z MF CAPACITOR .27MF 5% 50V
C 457 QFLC1HJ-223Z M CAPACITOR .022MF 5% 50V
C 458 QFLC1HJ-223Z M CAPACITOR .022MF 5% 50V
C 459 QFLC1HJ-183Z M CAPACITOR .018MF 5% 50V
C 460 QFLC1HJ-183Z M CAPACITOR .018MF 5% 50V
C 461 QFG32AJ-682Z PP CAPACITOR 6800PF 5% 100V
C 462 QFG32AJ-682Z PP CAPACITOR 6800PF 5% 100V
C 466 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 467 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 468 QETN1CM-477Z E CAPACITOR 470MF 20% 16V
C 469 QFLC1HJ-683Z M CAPACITOR .068MF 5% 50V
C 470 QFVJ1HJ-274Z MF CAPACITOR .27MF 5% 50V
C 471 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C 472 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C 473 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C 474 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C 475 EETC1HM-105ZJC E CAPACITOR
C 476 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V
C 488 EETC1HM-105ZJC E CAPACITOR
C 501 QUY150-050Y BUS WIRE
C 502 QUY150-050Y BUS WIRE
C 526 QETN1CM-477Z E CAPACITOR 470MF 20% 16V
C 527 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C 528 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C 530 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C 531 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C 532 QTE1C06-476Z E CAPACITOR
C 535 EETC1AM-107ZJC E CAPACITOR
C 571 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 575 QFVJ1HJ-184Z MF CAPACITOR .18MF 5% 50V
C 578 EETC1HM-105ZJC E CAPACITOR
C 585 EETC1HM-105ZJC E CAPACITOR
C 586 QDXB1CM-182Y C CAPACITOR
C 587 QCSB1HJ-330Y C CAPACITOR 33PF 5% 50V
C 588 QDGB1HK-681Y C CAPACITOR
C 589 QFLC1HJ-153Z M CAPACITOR .015MF 5% 50V
C 593 FQCS31HJ-470Z C CAPACITOR
C 594 QETN1AM-477Z E CAPACITOR 470MF 20% 10V
C 596 QDYB1CM-103Y C CAPACITOR
C 599 QETN0JM-108Z E CAPACITOR 1000MF 20% 6.3V
C 777 QTE1C06-476Z E CAPACITOR
C 980 QDVB1EZ-223Y C CAPACITOR
C 981 QCZ0202-155Z ML CC CAPACITOR 1.5MF
C 995 EETC1AM-107ZJC E CAPACITOR
C 998 QDYB1CM-822Y C CAPACITOR
C 999 QDYB1CM-822Y C CAPACITOR
CN 11 QGF1205F1-09 CONNECTOR
CN208 WJK0114-002A E-SI C WIRE C-B
CN209 WJK0071-002A CONN.WIRE ASSY
CN211 QGB2510K2-11 CONNECTOR
CN212 QGB2510K2-10 CONNECTOR
CN213 QGB2510K2-04 CONNECTOR
CN214 QJK015-071214 CONN.WIRE ASSY
CN218 QGA7901F1-03 CONNECTOR
CN219 QGA7901C1-04 CONNECTOR
CN220 QGD2504C1-03Z SOCKET
CN250 QGA7901C1-02 CONNECTOR
A
CN315 QGF1205C1-10 CONNECTOR
CN504 QGF1016F3-15 CONNECTOR
CN661 QGF1016F3-19 CONNECTOR
CN870 QGF1205C1-17 CONNECTOR
CN871 QGF1205C1-17 CONNECTOR
C1201 QETN1AM-227Z E CAPACITOR 220MF 20% 10V
C1202 QFLC1HJ-823Z M CAPACITOR .082MF 5% 50V
C1228 EETC1AM-107ZJC E CAPACITOR
D 411 1SS119-041-T2 SI DIODE
D 412 1SS119-041-T2 SI DIODE
D 426 DZ5.1BSB-T2 ZENER DIODE
D 431 DZ3.9BSB-T2 ZENER DIODE
D 432 DZ3.9BSB-T2 ZENER DIODE
D 434 DZ5.1BSB-T2 ZENER DIODE
D 572 1SS119-041-T2 SI DIODE
D 585 1SS119-041-T2 SI DIODE
D 586 DZ6.8BSC-T2 ZENER DIODE
D 587 DZ6.8BSC-T2 ZENER DIODE
D 592 1SS119-041-T2 SI DIODE
EP250 E409182-001SM GRAND TERMINAL
FT111 QNG0020-001Z FUSE CLIP
FT112 QNG0020-001Z FUSE CLIP
FT131 QNG0020-001Z FUSE CLIP
FT132 QNG0020-001Z FUSE CLIP
FT511 QNG0020-001Z FUSE CLIP
FT512 QNG0020-001Z FUSE CLIP
FT521 QNG0020-001Z FUSE CLIP
FT522 QNG0020-001Z FUSE CLIP
FW401 QUM155-09Z4Z4 PARA RIBON WIRE
FW710 QUM153-09DGZ4 FLAT WIRE
FW714 QUM156-18DGZ4 PARA RIBON WIRE
IC436 TDA7439 IC
IC466 BA3837 IC(VOCALFADER)
IC526 NJM4580D IC
J 411 QNN0420-001 PIN JACK
J 426 GP1FA550TZ OPT TRANSMITTER
J 999 QNN0420-001 PIN JACK
JA566 QNN0017-002 PIN JACK
L 001 QQR1277-001Z F.BEADS
L 546 QQR1277-001Z F.BEADS
L 566 QQR1277-001Z F.BEADS
Electrical parts list (Input board)
Block No. 02
Item
Parts number Parts name Ar
e
a
Remarks
A
