JVC MX-G880V

5-17
MX-G950V/MX-G880V
MX-G850V/MX-G750V
Item
Parts number Parts name Ar
e
a
Remarks
A
L 567 QQR1277-001Z F.BEADS
L 571 QQR1277-001Z F.BEADS
Q
401 2SC3576-JVC-T TRANSISTOR
Q
402 2SC3576-JVC-T TRANSISTOR
Q
481 2SC3576-JVC-T TRANSISTOR
Q
482 2SC3576-JVC-T TRANSISTOR
Q
483 KRA102M-T D.TRANSISTOR
Q
556 2SC3576-JVC-T TRANSISTOR
Q
557 2SC3576-JVC-T TRANSISTOR
Q
571 2SC2785/FE/-T TRANSISTOR
Q
572 2SC2785/FE/-T TRANSISTOR
Q
573 2SC2785/FE/-T TRANSISTOR
Q
585 2SC2785/FE/-T TRANSISTOR
Q
586 2SC2785/FE/-T TRANSISTOR
Q
884 2SC2785/FE/-T TRANSISTOR
Q
885 2SC3576-JVC-T TRANSISTOR
Q
886 2SC3576-JVC-T TRANSISTOR
Q
887 2SC2785/FE/-T TRANSISTOR
Q
888 2SC2785/FE/-T TRANSISTOR
Q
999 KRA102M-T D.TRANSISTOR
R 401 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 402 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 403 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 404 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 405 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 406 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 407 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 411 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R 412 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R 413 QRE141J-433Y C RESISTOR 43K 5% 1/4W
R 414 QRE141J-433Y C RESISTOR 43K 5% 1/4W
R 426 QRE141J-560Y C RESISTOR 56 5% 1/4W
R 431 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 432 QRE141J-303Y C RESISTOR 30K 5% 1/4W
R 434 QRJ146J-4R7X UNF C RESISTOR
A
4.7 5% 1/4W
R 435 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 436 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 437 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 438 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 439 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 440 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 441 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 442 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 443 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 444 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 466 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 467 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R 468 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R 469 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 470 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 471 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 472 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 473 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 474 QRE141J-513Y C RESISTOR 51K 5% 1/4W
R 475 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 493 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 494 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 496 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 526 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 528 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 529 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 530 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 532 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 534 QRE141J-204Y C RESISTOR 200K 5% 1/4W
R 536 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 537 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 541 QRE141J-204Y C RESISTOR 200K 5% 1/4W
R 557 QRE141J-243Y C RESISTOR 24K 5% 1/4W
R 558 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 563 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 564 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 571 QRE141J-302Y C RESISTOR 3.0K 5% 1/4W
R 572 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 577 QRE141J-274Y C RESISTOR 270K 5% 1/4W
R 581 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R 582 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 583 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 585 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 586 QRE141J-225Y C RESISTOR 2.2M 5% 1/4W
R 587 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 588 QRE141J-220Y C RESISTOR 22 5% 1/4W
R 593 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 771 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 772 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 773 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 774 QRE141J-223Y C RESISTOR
A
22K 5% 1/4W
R 775 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 885 QRE141J-243Y C RESISTOR 24K 5% 1/4W
R 991 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 994 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 995 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 997 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 998 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1000 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1001 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1002 ERX12SJR33E UNF.C.RESISTOR
A
R1202 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1203 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
S 500 QSW0812-001 VOLTAGE SWITCH
A
SP 21 VYSA1R3-049 SPACER
SP 22 VYSA1R3-049 SPACER
SP 23 VYSA1R3-049 SPACER
Electrical parts list (Input board)
Block No. 02
Item
Parts number Parts name Ar
e
a
Remarks
A
