JVC MX-G880V - Electrical parts list (Front board)

MX-G950V/MX-G880V
MX-G850V/MX-G750V
5-18
Item
Parts number Parts name Ar
e
a
Remarks
A
C 233 QFVJ1HJ-104Z MF CAPACITOR .10MF 5% 50V
C 302 EETC1HM-106ZJC E CAPACITOR
C 308 EETC1HM-106ZJC E CAPACITOR
C 310 EETC1HM-106ZJC E CAPACITOR
C 312 EETC1HM-106ZJC E CAPACITOR
C 360 EETC1CM-476ZJC E CAPACITOR
C 361 QDYB1CM-103Y C CAPACITOR
C 362 EETC1HM-226ZJC E CAPACITOR
C 801 FQCF31HP-103Z C CAPACITOR
C 803 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 804 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 805 QDGB1HK-102Y C CAPACITOR
C 808 QCSB1HJ-120Y C CAPACITOR 12PF 5% 50V
C 809 QCSB1HJ-180Y C CAPACITOR 18PF 5% 50V
C 815 EETC1HM-226ZJC E CAPACITOR
C 816 EETC1CM-476ZJC E CAPACITOR
C 817 EETC1HM-226ZJC E CAPACITOR
C 820 QCZ0202-155Z ML C CAPACITOR 1.5MF
C 821 QDYB1CM-103Y C CAPACITOR
C 823 QFVJ1HJ-334Z MF CAPACITOR .33MF 5% 50V
C 831 QDYB1CM-103Y C CAPACITOR
C 832 QDYB1CM-103Y C CAPACITOR
C 835 QDGB1HK-102Y C CAPACITOR
C 836 EETC1EM-106ZJC E CAPACITOR
C 837 EETC1AM-107ZJC E CAPACITOR
C 838 QDGB1HK-102Y C CAPACITOR
C 840 EETC1AM-107ZJC E CAPACITOR
C 862 EETC1HM-226ZJC E CAPACITOR
C 872 EETC1HM-224ZJC E CAPACITOR
C 889 EETC1HM-475ZJC E CAPACITOR
C 935 QDYB1CM-103Y C CAPACITOR
C 956 QDYB1CM-103Y C CAPACITOR
C 957 QDYB1CM-103Y C CAPACITOR
C 960 QDYB1CM-103Y C CAPACITOR
C 961 QDYB1CM-103Y C CAPACITOR
C 962 QDYB1CM-103Y C CAPACITOR
C 963 QDYB1CM-103Y C CAPACITOR
CN216 QGB2510K2-12 CONNECTOR
CN217 QGB2510K2-06 CONNECTOR
CN316 QGF1210G1-09 CONNECTOR
CN710 QGD2504C1-03Z SOCKET
CN860 QGF1205F1-17 CONNECTOR
CN861 QGF1205F1-17 CONNECTOR
CN880 QGF1210G1-24 FFC/FPC CONNE
CN890 QGF1205F1-24 CONNECTOR
CN911 QGD2503F1-07 SOCKET
C1004 QDGB1HK-102Y C CAPACITOR
C1005 QDGB1HK-102Y C CAPACITOR
C1006 QDGB1HK-102Y C CAPACITOR
C1021 QDGB1HK-102Y C CAPACITOR
C1022 QDGB1HK-102Y C CAPACITOR
C1023 QDGB1HK-102Y C CAPACITOR
C1034 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V
C1035 EETC1AM-107ZJC E CAPACITOR
C1036 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C1037 QDYB1CM-103Y C CAPACITOR
C1038 QDXB1CM-472Y C CAPACITOR
C1039 QDYB1CM-103Y C CAPACITOR
C1040 QDXB1CM-332Y C CAPACITOR
C1041 QDYB1CM-103Y C CAPACITOR
C1042 EETC1EM-226ZJC E CAPACITOR
C1043 QFVJ1HJ-474Z MF CAPACITOR .47MF 5% 50V
C1044 QDYB1CM-103Y C CAPACITOR
C1045 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C1046 EETC1HM-105ZJC E CAPACITOR
C1061 QETN1AM-227Z E CAPACITOR 220MF 20% 10V
C1062 EEKC1AM-107ZJC E CAPACITOR
C1063 EEKC1HM-475ZJC E CAPACITOR
C1064 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C1065 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C1066 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C1067 QEKC1HM-225Z E CAPACITOR 2.2MF 20% 50V
C1068 QEKC1HM-224Z E CAPACITOR .22MF 20% 50V
C1070 QDXB1CM-222Y C CAPACITOR
D 308 DZ5.6BSC-T2 ZENER DIODE
D 313 DZ8.2BSB-T2 ZENER DIODE
D 314 DZ13BSB-T2 ZENER DIODE
D 315 DZ9.1BSB-T2 ZENER DIODE
D 360 DZ5.1BSB-T2 ZENER DIODE
D 361 DZ9.1BSB-T2 ZENER DIODE
D 362 DZ6.8BSC-T2 ZENER DIODE
D 725 1SS119-041-T2 SI DIODE
D 801 1N4003S-T5 SI DIODE
D 803 1SS119-041-T2 SI DIODE
D 804 1SS119-041-T2 SI DIODE
D 805 1SS119-041-T2 SI DIODE
D 807 1N4003S-T5 SI DIODE
D 812 1SS119-041-T2 SI DIODE
D 831 DZ5.1BSB-T2 ZENER DIODE
D 832 DZ5.1BSB-T2 ZENER DIODE
D 860 1SS119-041-T2 SI DIODE
D 907 1SS119-041-T2 SI DIODE
D 918 L-192ZSRD-T LED
D 919 L-192ZSRD-T LED
D 920 L-192ZSRD-T LED
D 940 L-192ZSRD-T LED
D 941 L-192ZSRD-T LED
D 942 L-192ZSRD-T LED
D 943 L-192ZSRD-T LED
D 944 L-192ZSRD-T LED
D 945 L-192ZSRD-T LED
D 953 L-192ZSRD-T LED
D 954 L-192ZSRD-T LED
D 962 L-192ZSRD-T LED
D 964 1SS119-041-T2 SI DIODE
D1003 DZ2.4BSB-T2 ZENER DIODE
D1021 DZ5.1BSB-T2 ZENER DIODE
D1061 1SS119-041-T2 SI DIODE
D1062 DZ2.4BSB-T2 ZENER DIODE
FL801 QLF0081-001 FL DISPLAY TUBE
FW230 QUM153-11DGZ4 PARA RIBON WIRE
FW713 QUM153-33DGZ4 FLAT WIRE
FW915 QUM027-18Z4Z4 PARA RIBON WIRE
IC301 KIA78R05PI +5V REG.IC
A
IC303 L7808CP IC
A
IC304 L7812CP IC
A
IC305 L7809CP IC
A
IC810 MN101C35DEM IC
IC811 BU2092 IC
IC830 KIA7042AP-T IC
IC901 NJM4580L IC
IC902 BU9253AS IC
IC951 GP1U271X RF-RECEIVER
J 81 QNB0006-001 SPK TERMINAL
JS956 QSW0912-001 ROTARY SWITCH S/WOOFER VOL
JS960 QSW0911-001 ROTARY SWITCH S/MODE VOL
Electrical parts list (Front board)
Block No. 03
Item
Parts number Parts name Ar
e
a
Remarks
A
