JVC MX-G880V

3-15
MX-G950V/MX-G880V
MX-G850V/MX-G750V
Item
Parts number Parts name Ar
e
a
Remarks
A
Electrical parts list (Power board)
Block No. 01
Item
Parts number Parts name Ar
e
a
Remarks
A
C 201 QFKC2EK-104 METAL CAPACITOR .10MF 10% 250V
C 202 QFKC2EK-104 METAL CAPACITOR .10MF 10% 250V
C 203 QFKC2EK-104 METAL CAPACITOR .10MF 10% 250V
C 204 EETB1JM-478JC E CAPACITOR
C 205 EETB1JM-478JC E CAPACITOR
C 211 QFLC1HJ-823Z M CAPACITOR .082MF 5% 50V
C 212 QFLC1HJ-823Z M CAPACITOR .082MF 5% 50V
C 213 QFLC1HJ-823Z M CAPACITOR .082MF 5% 50V
C 214 EETB1HM-228JC AL E.CAPACITOR
C 215 EETB1HM-228JC AL E.CAPACITOR
C 216 QETN1VM-107Z E CAPACITOR 100MF 20% 35V
C 217 EETC2AM-476ZJC AL E.CAPACITOR
C 218 EETC1HM-226ZJC E CAPACITOR
C 219 QDYB1CM-103Y C CAPACITOR
C 220 EETC1HM-476ZJC AL E.CAPACITOR
C 221 EETC1HM-476ZJC E CAPACITOR
C 222 EETC1HM-476ZJC E CAPACITOR
C 253 EETB1EM-688JC AL E.CAPACITOR
C 280 EETC1HM-224ZJC E CAPACITOR
C 281 QETN1JM-476Z E CAPACITOR 47MF 20% 63V
C 372 EETC1HM-226ZJC E CAPACITOR
C 373 QDYB1CM-103Y C CAPACITOR
C 374 EETC1HM-226ZJC E CAPACITOR
C 601 QFVJ1HJ-683Z MF CAPACITOR .068MF 5% 50V
C 602 QFVJ1HJ-683Z MF CAPACITOR .068MF 5% 50V
C 603 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 604 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 605 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 606 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 607 QETN1JM-476Z E CAPACITOR 47MF 20% 63V
C 608 QETN1JM-476Z E CAPACITOR 47MF 20% 63V
C 609 QCSB1HJ-100Y C CAPACITOR 10PF 5% 50V
C 610 QCSB1HJ-100Y C CAPACITOR 10PF 5% 50V
C 611 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
C 612 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
C 613 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 614 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 615 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 616 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 621 QTE1V06-106Z E CAPACITOR
C 622 QTE1V06-106Z E CAPACITOR
C 623 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 624 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 639 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C 683 QFLC1HJ-823Z M CAPACITOR .082MF 5% 50V
C 703 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 704 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 705 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 706 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 707 QETN1JM-476Z E CAPACITOR 47MF 20% 63V
C 708 QETN1JM-476Z E CAPACITOR 47MF 20% 63V
C 709 QCSB1HK-4R7Y C CAPACITOR 4.7PF 10% 50V
C 710 QCSB1HK-4R7Y C CAPACITOR 4.7PF 10% 50V
C 711 QFZ0212-104Z MM CAPACITOR .10MF
C 712 QFZ0212-104Z MM CAPACITOR .10MF
C 713 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 714 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 715 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 716 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 721 QTE1V06-106Z E CAPACITOR
C 722 QTE1V06-106Z E CAPACITOR
C 723 EETC1AM-107ZJC E CAPACITOR
C 726 EETC1EM-106ZJC E CAPACITOR
C 729 EETC1CM-476ZJC E CAPACITOR
C 730 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C 731 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C 739 EETC1HM-105ZJC E CAPACITOR
C 790 EETC1EM-476ZJC E CAPACITOR
C 901 QDYB1CM-103Y C CAPACITOR
C 902 QDYB1CM-103Y C CAPACITOR
CN201 QGB2510J1-11 CONNECTOR
CN202 QGB2510J1-10 CONNECTOR
CN203 QGB2510J1-04 CONNECTOR
CN204 QGA3901C1-07 CONNECTOR
CN205 QGB2510J1-14 CONNECTOR
CN206 QGB2510J1-12 CONNECTOR
CN207 QGB2510J1-10 CONNECTOR
CN215 QGB2510K2-14 CONNECTOR
CN703 QGD2504C1-03Z SOCKET
CN704 QGD2504C1-03Z SOCKET
CN705 QGA2501C1-02 2P CONNECTOR
CN706 QGD2504C1-03Z SOCKET
D 201 1N5402M-20 DIODE
A
D 202 1N5402M-20 DIODE
A
D 203 1N5402M-20 DIODE
A
D 204 1N5402M-20 DIODE
A
D 211 1N5402M-20 DIODE
A
D 212 1N5402M-20 DIODE
A
D 213 1N5402M-20 DIODE
A
D 214 1N5402M-20 DIODE
A
D 217 1N4003S-T5 SI DIODE
A
D 218 1N4003S-T5 SI DIODE
A
D 219 DZ33BSC-T2 ZENER DIODE
D 220 DZ9.1BSB-T2 ZENER DIODE
D 227 1N4003S-T5 SI DIODE
A
D 233 2A02-M DIODE
A
D 234 2A02-M DIODE
A
D 280 DZ2.4BSB-T2 ZENER DIODE
D 369 DZ10BSC-T2 ZENER DIODE
D 370 DZ11BSC-T2 ZENER DIODE
D 619 1SS119-041-T2 SI DIODE
D 620 1SS119-041-T2 SI DIODE
D 622 DZ9.1BSB-T2 ZENER DIODE
D 703 DZ15BSC-T2 ZENER DIODE
D 704 DZ15BSC-T2 ZENER DIODE
D 719 1SS119-041-T2 SI DIODE
D 720 1SS119-041-T2 SI DIODE
D 723 DZ36BSA-T2 ZENER DIODE
D 724 DZ36BSA-T2 ZENER DIODE
D 726 1SS119-041-T2 SI DIODE
D 728 1SS119-041-T2 SI DIODE
D 790 1SS119-041-T2 SI DIODE
D 904 L-192ZSRD-T LED
D 905 L-192ZSRD-T LED
EP201 QNZ0136-001Z EARTH PLATE
EP202 QNZ0136-001Z EARTH PLATE
FW707 QUM153-09Z4Z4 PARA RIBON WIRE
FW901 QUM027-13DGZ4 PARA RIBON WIRE
IC602 STK402-050 IC(HYBRID)
A
IC701 STK412-010 IC(HYBRID)
A
JS901 QSW0911-001 ROTARY SWITCH
L 601 QQLZ035-R39 INDUCTOR
L 602 QQLZ035-R39 INDUCTOR
L 701 QQLZ035-R39 INDUCTOR
L 702 QQLZ035-R39 INDUCTOR
Q
201 2SB740/BC/-T TRANSISTOR
