MX-G950V/MX-G880V
MX-G850V/MX-G750V
3-16
Item
Parts number Parts name Ar
e
a
Remarks
A
Q
240 2SC2785/FE/-T TRANSISTOR
Q
372 KTA1023/OY/-T TRANSISTOR
Q
373 KRA104M-T D.TRANSISTOR
Q
374 KRC104M-T D.TRANSISTOR
Q
601 KTA1268/GL/-T TRANSISTOR
Q
602 KTA1268/GL/-T TRANSISTOR
Q
612 2SA1175/FE/-T TRANSISTOR
Q
613 KRC102M-T D.TRANSISTOR
Q
680 2SK301/PQ/-T FET
Q
701 KTA1268/GL/-T TRANSISTOR
Q
702 KTA1268/GL/-T TRANSISTOR
Q
710 2SA965/OY/-T TRANSISTOR
Q
711 KTC3200/GL/-T TRANSISTOR
Q
712 KTA1268/GL/-T TRANSISTOR
Q
713 KTC1027/OY/-T TRANSISTOR
Q
726 2SC2389S/SE/-T TRANSISTOR
Q
727 KTA1268/GL/-T TRANSISTOR
Q
728 2SC2785/FE/-T TRANSISTOR
Q
733 2SC3576-JVC-T TRANSISTOR
Q
734 2SC3576-JVC-T TRANSISTOR
Q
735 2SC3576-JVC-T TRANSISTOR
Q
736 2SC3576-JVC-T TRANSISTOR
Q
737 KRA111M-T D.TRANSISTOR
Q
790 2SC2785/FE/-T TRANSISTOR
Q
791 2SC2785/FE/-T TRANSISTOR
Q
792 KTC3203/OY/-T TRANSISTOR
Q
901 KRC102M-T D.TRANSISTOR
R 202 QRZ9042-2R2X F RESISTOR
A
2.2 1/4W
R 203 QRE141J-752Y C RESISTOR 7.5K 5% 1/4W
R 204 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 205 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 215 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 216 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 217 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 218 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 220 QRJ146J-470X UNF C RESISTOR
A
47 5% 1/4W
R 242 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 246 QRJ146J-1R0X UNF C RESISTOR
A
1.0 5% 1/4W
R 247 QRJ146J-1R0X UNF C RESISTOR
A
1.0 5% 1/4W
R 248 QRJ146J-1R0X UNF C RESISTOR
A
1.0 5% 1/4W
R 249 QRJ146J-1R0X UNF C RESISTOR
A
1.0 5% 1/4W
R 281 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 283 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 284 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 384 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 385 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 389 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 601 QRJ146J-101X UNF C RESISTOR
A
100 5% 1/4W
R 602 QRJ146J-101X UNF C RESISTOR
A
100 5% 1/4W
R 603 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 604 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 605 QRJ146J-102X UNF C RESISTOR
A
1.0K 5% 1/4W
R 606 QRJ146J-102X UNF C RESISTOR
A
1.0K 5% 1/4W
R 607 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 608 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 613 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 614 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 615 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 616 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 617 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 618 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 619 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 620 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 621 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 623 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 639 QRL01DJ-821X OMF RESISTOR
A
820 5% 1/1W
R 640 QRL01DJ-821X OMF RESISTOR
A
820 5% 1/1W
R 653 QRT01DJ-R22X MF RESISTOR
A
5% 1W
R 655 QRT01DJ-R22X MF RESISTOR
A
5% 1W
R 666 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 667 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 668 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 674 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 675 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 676 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 680 QRE141J-105Y C RESISTOR 1.0M 5% 1/4W
R 681 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R 682 QRE141J-475Y C RESISTOR 4.7M 5% 1/4W
R 701 QRJ146J-470X UNF C RESISTOR
A
47 5% 1/4W
R 702 QRJ146J-470X UNF C RESISTOR
A
47 5% 1/4W
R 703 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 704 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 705 QRJ146J-821X UNF C RESISTOR
A
820 5% 1/4W
R 706 QRJ146J-821X UNF C RESISTOR
A
820 5% 1/4W
R 707 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 708 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 713 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 714 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 715 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 716 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 717 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 718 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 719 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 720 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 721 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 722 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 723 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 724 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 725 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 726 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 727 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 728 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 729 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 730 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 733 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 734 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 735 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 736 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 739 QRL01DJ-821X OMF RESISTOR
A
820 5% 1W
R 740 QRL01DJ-821X OMF RESISTOR
A
820 5% 1W
R 741 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 742 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 753 QRZ0197-R22 C RESISTOR 1W
R 754 QRZ0197-R22 C RESISTOR 1W
R 761 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 762 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 766 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 768 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 769 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 774 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 775 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 776 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 777 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 778 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 786 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 787 QRE141J-103Y C RESISTOR 10K 5% 1/4W
Electrical parts list (Power board)
Block No. 01
Item
Parts number Parts name Ar
e
a
Remarks
A
