JVC MX-GA3V User Manual

3-10
Electrical parts list
Main board
Block No. [0][1][0][0]
 Symbol No. Part No. Part Name Description Local
IC102 BA15218F IC BI113241
IC103 TDA7440D IC BI113231
IC301 BA3837 IC BI113891
 IC304 STK402-070 IC BI113201
IC401 TA8189N IC BI101251
IC851 BU9253AS IC BI113881
IC852 BA15218F IC BI113241
Q101 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q103 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q104 KTA1267GR TRANSISTOR BI2KTA1267GP000
Q105 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q201 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q203 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q204 KTA1267GR TRANSISTOR BI2KTA1267GP000
Q205 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q301 KRA107M DIGI TRANSISTOR BI2KRA107MP000
Q302 KTC3200GR TRANSISTOR BI2KTC3200P0008
Q303 KTC3203Y TRANSISTOR BI2KTC3203YP000
Q304 KTA1267GR TRANSISTOR BI2KTA1267GP000
Q305 DTC144ES TRANSISTOR
BI2DTC144ESP00
2
Q307 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q308 DTC144ES TRANSISTOR
BI2DTC144ESP00
2
Q309 KTA1273Y TRANSISTOR BI2KTA1273P0008
Q310 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q311 KTA1273Y TRANSISTOR BI2KTA1273P0008
Q312 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q313 KTA1273Y TRANSISTOR BI2KTA1273P0008
Q314 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
Q315 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q316 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q317 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q318 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
Q319 KTA1273Y TRANSISTOR BI2KTA1273P0008
Q320 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
Q321 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
Q322 KRA107M DIGI TRANSISTOR BI2KRA107MP000
Q323 KRA107M DIGI TRANSISTOR BI2KRA107MP000
Q324 KRA107M DIGI TRANSISTOR BI2KRA107MP000
Q325 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
Q327 KTA1267GR TRANSISTOR BI2KTA1267GP000
Q331 KTC3200GR TRANSISTOR BI2KTC3200P0008
Q332 KTA1268GR TRANSISTOR BI2KTA1268GP000
Q333 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
Q334 KRA107M DIGI TRANSISTOR BI2KRA107MP000
Q335 KRA107M DIGI TRANSISTOR BI2KRA107MP000
Q336 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q337 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q338 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q339 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
Q401 2SD2144S TRANSISTOR
BI2SD2144SVP00
2
Q402 2SD2144S TRANSISTOR
BI2SD2144SVP00
2
Q403 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q404 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q405 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q501 2SD2144S TRANSISTOR
BI2SD2144SVP00
2
Q502 2SD2144S TRANSISTOR
BI2SD2144SVP00
2
Q503 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q504 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q505 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q851 2SD2144S TRANSISTOR
BI2SD2144SVP00
2
Q852 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q853 DTA114YS TRANSISTOR BI2DTA114YSP002
Q901 2SA934R TRANSISTOR BI2SA934RP0007
Q902 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
Q903 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
 Q904 KTB1366Y TRANSISTOR BI2KTB1366Y8
Q905 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q906 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
 Q907 KTB1366Y TRANSISTOR BI2KTB1366Y8
Q908 KTA1267GR TRANSISTOR BI2KTA1267GP000
Q909 KRA107M DIGI TRANSISTOR BI2KRA107MP000
Q910 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
Q911 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q912 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
D304 1SS133 FR DIODE BI31SS133M0007
D305 1SS133 FR DIODE BI31SS133M0007
D307 MTZJ5.1B Z DIODE BI3MTZJ5.1BM000
D308 1SS133 FR DIODE BI31SS133M0007
D309 1SS133 FR DIODE BI31SS133M0007
D310 1SS133 FR DIODE BI31SS133M0007
D311 1SS133 FR DIODE BI31SS133M0007
D312 1SS133 FR DIODE BI31SS133M0007
D313 1SS133 FR DIODE BI31SS133M0007
D314 1SS133 FR DIODE BI31SS133M0007
D321 1SS133 FR DIODE BI31SS133M0007
D322 1SS133 FR DIODE BI31SS133M0007
D323 1N4001 FR DIODE BI31N40011
D324 1SS133 FR DIODE BI31SS133M0007
D325 1SS133 FR DIODE BI31SS133M0007
D326 1SS133 FR DIODE BI31SS133M0007
D327 1SS133 FR DIODE BI31SS133M0007
D328 1SS133 FR DIODE BI31SS133M0007
D329 1SS133 FR DIODE BI31SS133M0007
D330 1SS133 FR DIODE BI31SS133M0007
D331 1SS133 FR DIODE BI31SS133M0007
D332 1SS133 FR DIODE BI31SS133M0007
D333 1SS133 FR DIODE BI31SS133N0007
D851 1SS133 FR DIODE BI31SS133M0007
D852 MTZJ5.1B Z DIODE BI3MTZJ5.1BM000
D853 MTZJ8.2B Z DIODE BI3MTZJ8.2BM000
 D901 RS603M SI DIODE BI3RS603M1
 D902 1N5393 SI DIODE
BI31N5393GWN00
0
 D903 1N5393 SI DIODE
BI31N5393GWN00
0
 D904 1N5393 SI DIODE
BI31N5393GWN00
0
