3-11
Tuner board
Block No. [0][2][0][0]
Front board
Block No. [0][3][0][0]
 D905 1N5393 SI DIODE
BI31N5393GWN00
0
 D906 1N4001 FR DIODE BI31N40011
D907 MTZJ33C Z DIODE
BI3MTZJ33CM000
7
D908 MTZJ6.2B Z DIODE BI3MTZJ6.2BM000
D909 1SS133 FR DIODE BI31SS133M0007
D910 MTZJ6.2 B Z DIODE BI3MTZJ6.2BM000
D911 MTZJ5.6B Z DIODE BI3MTZJ5.6BM000
D912 MTZJ13C Z DIODE
BI3MTZJ13CM000
7
D913 MTZJ12C Z DIODE
BI3MTZJ12CM000
7
D915 MTZJ6.8B Z DIODE BI3MTZJ6.8BM000
D916 1SS133 FR DIODE BI31SS133M0007
C117 BI5283A TIN COATED 0.6MM
C217 BI5283A TIN COATED 0.6MM
C302 BI5283A TIN COATED 0.6MM
C401 BI5283A TIN COATED 0.6MM
C501 BI5283A TIN COATED 0.6MM
 C905 BICE33863MSN3 E CAPACITOR 3300UF/63V
 C906 BICE33863MSN3 E CAPACITOR 3300UF/63V
 C911 BICE47825M0 E CAPACITOR E 4700-25 M
 R127 BIRF1510045N000 FUSED RESISTOR 150OHM 1/4W
 R132 BIRF3910045N000 FUSED RESISTOR 390 OHM J 1/4W
 R133 BIRF3910045N000 FUSED RESISTOR 390 OHM J 1/4W
 R227 BIRF1510045N000 FUSED RESISTOR 150OHM 1/4W
 R232 BIRF3910045N000 FUSED RESISTOR 390 OHM J 1/4W
 R233 BIRF3910045N000 FUSED RESISTOR 390 OHM J 1/4W
 R362 BIRF0100045N000 FUSED RESISTOR 1OHM 1/4W
 R902 BIRF1010045N000 FUSI RESISTOR 100 OHM J 1/4W
 R908 BIRF0100025N000 FUSED RESISTOR 1OHM 0.5W
L101 BI2600702 FIXED INDUCTOR 1.0UH
L201 BI2600702 FIXED INDUCTOR 1.0UH
L301 BI605071 IFT 10MM 864306
L305 BI26100000KN008 FIXED INDUCTOR 10UH / 52MM
L1051 BI26470000KM002 FIXED INDUCTOR 47UH/26MM
L1052 BI26470000KM002 FIXED INDUCTOR 47UH/26MM
L1054 BI26004700MM002 FIXED INDUCTOR 0.47UH / 26MM
BI304 BI18A843556N000 FILTER BEAD 52MM
CD75 BI5283A TIN COATED 0.6MM
CN2 BI12S140017 CONNECTOR 14P V /1.25MM
CN3 BI12S130027 CONNECTOR 13P /1.25MM
CN5 BI12S110020 CONNECTOR 11P/1.25MM
CN101 BI12S40047 CONNECTOR 4 PINS/ 4P
CN202 BI12S100034 CONNECTOR 10P V
CN203 BI12S800421 FFC CONNECTOR 8P /1.25MM
CN305 BI12S130027 CONNECTOR 13P /1.25MM
CN307 BI12S30039 CONNECTOR 3P /2MM
CN308 BI12S80024 CONNECTOR 8P/ 2MM
CN850 BI12S400551 CONNECTOR 4P/PITCH2.0MM
CN951 BI12P90052 CONNECTOR ASSY 9P
FB306 BI18A843556N000 FILTER BEAD 52MM
FW951 BI12S90048 CONNECTOR 9P /2.5MM
J303 BI23F0251 SP 4P TERMINAL SP 4P
J1053 BI23B0112 MIC JACK 3.5M
JA301 BI23B0931 RCA W/R JACK 2 RCA
PN1 BI2004771 P.C.B. TERMINAL 0
PN2 BI2004771 P.C.B. TERMINAL 0
PN3 BI11A050M0 BLACK WIRE 50MM UL100
PN4 BI11A050M0 BLACK WIRE 50MM UL1007
PN5 BI11A050M0 BLACK WIRE 50MM UL1007
PN6 BI11A050M0 BLACK WIRE 50MM UL1007
PN8 BI2004771 P.C.B. TERMINAL
PWB BI251172G01V MAIN PWB
RY301 BI8RL00071 RELAY G5PA-2
 S999 BI804351 SWITCH C2C TYPE
TB901 BI201323010101 TERMINAL PLUG 1P MSC
TB902 BI201323010101 TERMINAL PLUG 1P MSC
W1051 BI12P402341 CONNECTOR 4PINS /2.5MM
XXX BI202323010101 HEATSINK-AMP AL T=1.0MM
XXX BIRT000611B3 SCREW 3XL8MM
XXX BI201771010101 TOOTH WASHER M2.6
XXX BI11TT80H1 T&TWIRE 80MM RED
XXX BI11TT80H2 T&TWIRE 80MM RED
 Symbol No. Part No. Part Name Description Local
XXX BI11TT80H3 T&TWIRE 80MM RED
XXX BI11TT80H4 T&TWIRE 80MM RED
XXX BI11TT80H5 T&TWIRE 80MM RED
XXX BI11TT80H6 T&TWIRE 80MM RED
 Symbol No. Part No. Part Name Description Local
IC1 TA2104BN IC BI105092
IC2 TC9257P IC BI114251
Q1 KTC3194 TRANSISTOR BI2KTC3194P0008
Q2 KTC3195 TRANSISTOR BI2KTC3195YP000
Q3 DTA114YS TRANSISTOR BI2DTA114YSP002
Q4 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
Q5 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
Q6 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
Q7 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q8 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q9 KTC3199GR TRANSISTOR
BI2KTC3199GP00
0
Q10 KTA1267GR TRANSISTOR BI2KTA1267GP000
Q11 DTC114YS TRANSISTOR
BI2DTC114YSP00
2
D1 1SS133 FR DIODE BI31SS133M0007
D2 1SS133 FR DIODE BI31SS133M0007
D3 1SS133 FR DIODE BI31SS133M0007
D4 1SS133 FR DIODE BI31SS133M0007
D5 1SS133 FR DIODE BI31SS133M0007
D6 1SS133 FR DIODE BI31SS133M0007
D7 BI3SVC203SPP000 VARACTOR DIODE 12.7MM
D8 BI3SVC203SPP000 VARACTOR DIODE 12.7MM
D10 1SS133 FR DIODE BI31SS133M0007
 R74 BIRF3300045M000 FUSI RESISTOR 33OHM J 1/4W
L1 BI26022000KM002 FIXED INDUCTOR 2.2UH /26MM
L2 BI605081 AM PACK COIL 0469-001
L3 BI7A0170 FM COIL 0.6MM
L4 BI7A0171 FM COIL 0.4MM
L5 BI26101000KM002 FIXED INDUCTOR 100UH/ 26MM
L6 BI26101000KM002 FIXED INDUCTOR 100UH/ 26MM
L50 BI26221000KM002 FIXED INDUCTOR 220UH /26MM
T1 BI2901541 CF&COIL 450KHZ
CF1 BI29LT10.7MP015 CERAMIC 10.7MHZ
CF2 BI29LT10.7MP015 CERAMIC 10.7MHZ
CF3 BI2901221 CERAMIC 10.7 MHZ
JA302 BI23F0101 TERMINAL ANT 4P 4P
LC1 BI29GFMB3TP0151 BAND PASS 108MHZ
N202A BI12S100034 CONNECTOR 10P/P1.25MM
PWB BI251174G01V TUNER PWB
X1 BI2102341 CRYSTAL 7.2MHZ
XXX BI202304010101 HLDR-TUNNER 0.5MM
 Symbol No. Part No. Part Name Description Local
IC701 TMP87CM78 IC BI114261
IC702 RPM6938-V4 RM.RECEIVER BI105231
IC703 S-80819 IC BI114351
 Symbol No. Part No. Part Name Description Local
