ADJUSTMENT
4.1 Alignment and adjustment
4.1.1 Tuner
* Adjustment Location of Tuner board
Fig.1 OSC Voltage
AM(MW) OSC
Adjustment
Output
1~7.0±0.5V
Received FREQ.
Adjustment
point
522~1611 kHz
MO
AM(MW) RF
Adjustment
ITEM
594 kHz
MA
Maximum
Output (Fig.1)
LW OSC
Adjustment
146~290 kHz
LO
2~7.0±0.5V
LW RF
Adjustment
150 kHz
LA
Maximum
Output (Fig.1)
Main
board
VT GND
TESTER
