SCHEMATIC DIAGRAMS
COMPACT COMPONENT SYSTEM
No.MB160SCH
2004/5
COPYRIGHT 2004 VICTOR COMPANY OF JAPAN, LTD.
MX-GB6,MX-GB5
CD-ROM No.SML200405
Contents
SP-MXGB6 SP-MXGB6
SP-MXGB5 SP-MXGB5
CA-MXGB6
CA-MXGB5
J ----------------------------- U.S.A.
C -------------------------- Canada
Area suffix
Wiring diagram ------------------------------------------------------- 2-1
Blcok diagram -------------------------------------------------------- 2-3
Standard schematic diagrams ----------------------------------- 2-5
Printed circuit boards -------------------------------------- 2-17 to 20
