JVC MX-GB6

3-16
CD board
Block No. [0][4][0][0]
XXXXX 3602-000147 FUSE-CLIP RFS5
XXXXX 3602-000147 FUSE-CLIP RFS6
XXXXX 3602-000147 FUSE-CLIP RFS7
XXXXX 3602-000147 FUSE-CLIP RFS8
XXXXX 3602-000147 FUSE-CLIP RFS9
XXXXX AH41-00673A PCB AMP
 Symbol No. Part No. Part Name Description Local
IC101 KB9226 IC 1204-001799
IC201 S5L9279X01 IC 1204-002230
IC301 KA9258D IC 1003-000179
IC302 FAN8082 IC 1003-001418
IC303 FAN8082 IC 1003-001418
IC501 12L1616A IC 1105-001261
Q101 KSA812 TRANSISTOR 0501-000314
Q302 KSC1008 TRANSISTOR 0501-000010
Q303 KSC1008 TRANSISTOR 0501-000010
D201 DAN217 DIODE 0401-000008
D301 1N5392 DIODE 0402-000151
D302 UZ3.9B Z DIODE 0403-000344
D304 UZ6.2BSB Z DIODE 0403-000361
D305 UZ2.7BSB Z DIODE 0403-001220
D306 SB01-05CP DIODE 0404-000144
D307 UZ4.7BM Z DIODE 0403-000352
C103 2203-000892 CHIP.CAPACITOR 4.7nF
C104 2203-000892 CHIP.CAPACITOR 4.7nF
C105 2401-000778 E CAPACITOR 220uF 20% 10V
C107 2401-001625 E CAPACITOR 6.8uF 20% 50V
C109 2203-000203 CHIP.CAPACITOR 100nF
C110 2203-000203 CHIP.CAPACITOR 100nF
C111 2203-001537 CHIP.CAPACITOR 1nF
C112 2203-000203 CHIP.CAPACITOR 100nF
C113 2203-000802 CHIP.CAPACITOR 33nF
C114 2404-000148 C CAPACITOR 1uF
C115 2203-000260 CHIP.CAPACITOR 10nF
C116 2203-002494 CHIP CAPACITOR 470nF
C117 2203-000260 CHIP.CAPACITOR 10nF
C118 2401-000438 E CAPACITOR 10uF 20% 25V
C119 2203-001137 CHIP.CAPACITOR 68nF
C120 2203-000203 CHIP.CAPACITOR 100nF
C121 2203-001064 CHIP.CAPACITOR 56nF 10% 50V
C122 2203-000840 CHIP.CAPACITOR 0.39nF
C123 2203-000495 CHIP.CAPACITOR 2.2nF
C124 2203-000595 CHIP.CAPACITOR 0.22nF
C125 2203-000203 CHIP.CAPACITOR 100nF
C126 2203-000203 CHIP.CAPACITOR 100nF
C127 2203-000802 CHIP.CAPACITOR 33nF
C128 2401-000778 E CAPACITOR 220uF 20% 10V
C129 2203-001537 CHIP.CAPACITOR 1nF
C130 2203-000260 CHIP.CAPACITOR 10nF
C131 2203-001551 CHIP.CAPACITOR 1.5nF
C132 2203-000609 CHIP.CAPACITOR 22nF
C133 2203-001137 CHIP.CAPACITOR 68nF
C134 2401-000778 E CAPACITOR 220uF 20% 10V
C135 2401-000778 E CAPACITOR 220uF 20% 10V
C136 2202-000780 C CAPACITOR 100nF
C140 2203-000239 CHIP CAPACITOR 0.1nF
C141 2203-000239 CHIP CAPACITOR 0.1nF
C142 2203-000239 CHIP CAPACITOR 0.1nF
C143 2203-000260 CHIP.CAPACITOR 10nF
C201 2203-000787 CHIP.CAPACITOR 0.33nF
C202 2203-000203 CHIP.CAPACITOR 100nF
C203 2401-000240 E CAPACITOR 100uF 20% 10V
C204 2203-000787 CHIP.CAPACITOR 0.33nF
C205 2203-000787 CHIP.CAPACITOR 0.33nF
C207 2401-000240 E CAPACITOR 100uF 20% 10V
C208 2203-000203 CHIP.CAPACITOR 100nF
 Symbol No. Part No. Part Name Description Local
C210 2401-000240 E CAPACITOR 100uF 20% 10V
C211 2203-000203 CHIP.CAPACITOR 100nF
C214 2203-000203 CHIP.CAPACITOR 100nF
C215 2401-000240 E CAPACITOR 100uF 20% 10V
C216 2203-000203 CHIP.CAPACITOR 100nF
C217 2401-000240 E CAPACITOR 100uF 20% 10V
C218 2203-000203 CHIP.CAPACITOR 100nF
C219 2401-000240 E CAPACITOR 100uF 20% 10V
C220 2203-000203 CHIP.CAPACITOR 100nF
C221 2401-000240 E CAPACITOR 100uF 20% 10V
C222 2203-001619 CHIP.CAPACITOR 0.027nF
C223 2203-001619 CHIP.CAPACITOR 0.027nF
C224 2202-000780 C CAPACITOR 100nF
C226 2203-000203 CHIP.CAPACITOR 100nF
C227 2203-000203 CHIP.CAPACITOR 100nF
C230 2203-000239 CHIP CAPACITOR 0.1nF
C231 2203-000239 CHIP CAPACITOR 0.1nF
C232 2203-000239 CHIP CAPACITOR 0.1nF
C233 2203-000239 CHIP CAPACITOR 0.1nF
C302 2401-001102 E CAPACITOR 330uF 20% 16V
C303 2401-000240 E CAPACITOR 100uF 20% 10V
C304 2401-000240 E CAPACITOR 100uF 20% 10V
C308 2203-000203 CHIP.CAPACITOR 100nF
C310 2203-000203 CHIP.CAPACITOR 100nF
C401 2203-000787 CHIP.CAPACITOR 0.33nF
C406 2203-000203 CHIP.CAPACITOR 100nF
C407 2202-000780 C CAPACITOR 100nF
C501 2203-000203 CHIP.CAPACITOR 100nF
C502 2203-000203 CHIP.CAPACITOR 100nF
C503 2203-000203 CHIP.CAPACITOR 100nF
C206R 2401-001954 E CAPACITOR 4.7uF 20% 50V
C209R 2203-000495 CHIP.CAPACITOR 2.2nF
C212L 2401-001954 E CAPACITOR 4.7uF 20% 50V
C213L 2203-000495 CHIP.CAPACITOR 2.2nF
R101 2007-000457 CHIP RESISTOR 18KOHM 5% 1/8W
R102 2007-000444 CHIP.RESISTOR
180KOHM 5% 1/
8W
R103 2007-000001 CHIP.RESISTOR 68KOHM 5% 1/8W
R104 2007-000468 CHIP.RESISTOR 1KOHM 5% 1/8W
R105 2007-000477 CHIP.RESISTOR 1MOHM 5% 1/8W
R106 2007-001177 CHIP.RESISTOR 8.2KOHM 5% 1/8W
R107 2007-000546 CHIP.RESISTOR 20KOHM 5% 1/8W
R108 2001-000331 C RESISTOR 12KOHM 5% 1/8W
R109 2007-000300 CHIP.RESISTOR 10KOHM 5% 1/8W
R110 2007-000300 CHIP.RESISTOR 10KOHM 5% 1/8W
R111 2007-000282 CHIP.RESISTOR
100KOHM 5% 1/
8W
R112 2007-001039 CHIP.RESISTOR 56KOHM 5% 1/8W
R113 2007-000409 CHIP.RESISTOR 15KOHM 5% 1/8W
R114 2007-000941 CHIP.RESISTOR 47KOHM 5% 1/8W
R115 2007-000338 CHIP.RESISTOR
120KOHM 5% 1/
8W
R116 2007-000338 CHIP.RESISTOR
120KOHM 5% 1/
8W
R117 2007-001039 CHIP.RESISTOR 56KOHM 5% 1/8W
R118 2007-001208 CHIP.RESISTOR 82KOHM 5% 1/8W
R119 2007-000653 CHIP.RESISTOR 27KOHM 5% 1/8W
R120 2007-000941 CHIP.RESISTOR 47KOHM 5% 1/8W
R121 2007-000308 CHIP.RESISTOR 10OHM 5% 1/8W
R122 2007-001208 CHIP.RESISTOR 82KOHM 5% 1/8W
R123 2007-001039 CHIP.RESISTOR 56KOHM 5% 1/8W
R124 2007-001039 CHIP.RESISTOR 56KOHM 5% 1/8W
R125 2007-001039 CHIP.RESISTOR 56KOHM 5% 1/8W
R126 2007-001039 CHIP.RESISTOR 56KOHM 5% 1/8W
R127 2007-001208 CHIP.RESISTOR 82KOHM 5% 1/8W
R128 2007-001216 CHIP.RESISTOR 82OHM 5% 1/8W
R201 2007-000290 CHIP.RESISTOR 100OHM 5% 1/8W
R202 2007-000282 CHIP.RESISTOR
100KOHM 5% 1/
8W
R207 2007-000477 CHIP.RESISTOR 1MOHM 5% 1/8W
R210 2007-000872 CHIP.RESISTOR 4.7KOHM 5% 1/8W
R211 2007-000300 CHIP.RESISTOR 10KOHM 5% 1/8W
R212 2007-000572 CHIP.RESISTOR 220OHM 5% 1/8W
R213 2007-000572 CHIP.RESISTOR 220OHM 5% 1/8W
R214 2007-000572 CHIP.RESISTOR 220OHM 5% 1/8W
R215 2007-000572 CHIP.RESISTOR 220OHM 5% 1/8W
R216 2007-000931 CHIP.RESISTOR 470OHM 5% 1/8W
R217 2007-000931 CHIP.RESISTOR 470OHM 5% 1/8W
 Symbol No. Part No. Part Name Description Local
