MX-GT80/MX-GT90
1-8
Remove the four screws E on the bottom of the
body.
Release the two joints a on the lower right and left
sides of the body using a screwdriver, and remove
the front panel assembly toward the front.
4.
5.
Fig.8
Fig.9
Fig.10
E
(Bottom)
Front panel assembly
Joint a
Joint a
Front panel assembly
Front panel assembly
