MX-K1
3-3
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
1 GJA2031003001C CASSETTE DOOR L 1
2 GJA2032001001C CASSETTE DOOR R 1
3 GJ4A05303001B0 VOLUME KNOB 1 VOLUME
4 GJ460170330201 JVC LOGO 1
5 GJA2020061001C 1
6 GJ4C05316003C0 LENS 1 DISPLAY
7 GJ772007940101 LABEL 1
8 GJ763000320106 FELT SHEET 4 10X10MM T=2MM
9 GJ660490020101 GEAR 2
10 GJ660490030101 GEAR BASE 2
11 GJ4D04048001A1 LOCK HOLDER 2
12 GJ422253701 SPRING 2 LOCK
13 GJ460400250101 HOLDER 2 DOOR LOCKER
14 -------------- CD SWITCH PCB1 1 ASS'Y
15 -------------- CONTROL PCB 1 ASS'Y
16 -------------- HEAD PHONE PCB 1 ASS'Y
17 GJ373020041000 DISPLAY 1 BJ828GNK
18 GJ793000150001 SPONGY 2 8X20XT0.8 MM W/
19 GJ560530400101 DISPLAY BRACKET 2 DISPLAY
20 -------------- CD SWITCH PCB2 1 ASS'Y
21 -------------- CASSETTE MECH 1 CMAT6Z219A ASS'
22 GJ560530200101 BOTTOM CASE 1
23 GJ4B05315001E0 CD FITTING 1
24 GJ727450540503 SOLDER TAG 1
25 GJ336660190013 POWER TRANS
A
1 AC120V/60HZT951
26 -------------- AC POWER PCB 1 ASS'Y
27 GJ780000180100 HEAT SINK 1
28 -------------- POWER AMP PCB 1
29 GJ560170100101 BRACKET A 1
30 GJ560170110101 BRACKET B 1
31 GJ780000340100 HEAT SINK 1
32 -------------- MAIN PCB 1
33 GJ560170040101 PCB BRACKET 1
34 -------------- CD CHANGER UNIT 1 910-EXLM75-03
35 GJ560530310212 REAR CASE 1
36 GJ560530100101 TOP CASE 1
37 GJ711001850101 SPRING 1 CASS DOOR R
38 GJ711001840100 SPRING 1 CASS DOOR L
39 GJ560170290101 BRACKET 1
40 GJ796000030000 CORD BUSHING 1
41 GJ732000010101 POWERCORD BAND 1
42 GJ702244300810 SCREW 15 TT 3X8 +BV TYP
43 GJ702244260810 SCREW 16 TT 2.6X8 +BV TY
44 GJ702244301010 SCREW 5 TT 3X10 +BV TYP
45 GJ702244301810 SCREW 1 TT 3X18 +BV TYP
46 GJ702244301410 SCREW 1 TT 3X14 +BV TYP
47 GJ702244300610 SCREW 16 TT 3X6 +BV TYPE
48 GJ702244300650 SCREW 2 TT 3X6 +BV TYPE
F.CABINET ASS'Y
(General assembly)
To Next Page
