JVC MX-K1 Service Manual

MX-K1
3-18
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 03
A
R 910 GJ250032232199 CARBON RESISTOR 1/4WM J 22K
R 911 GJ250033322199 CARBON RESISTOR 1/4WM J 3.3K
R 912 GJ250034712199 CARBON RESISTOR 1/4WM J 470
R 913 GJ250034712199 CARBON RESISTOR 1/4WM J 470
R 914 GJ250031092199 CARBON RESISTOR 1/4WM J 1
R 915 GJ250031092199 CARBON RESISTOR 1/4WM J 1
R 916 GJ250031092199 CARBON RESISTOR 1/4WM J 1
R 917 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 918 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
(Amp board)
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 04
A
F 951 GJ369000680009 FUSE
A
250V D=5X20MM
F 952 GJ369000600009 FUSE
A
250V D=5X20MM
FW951 GJ353090190107 CABLE FLAT CABLE FLAT 9PIN
HF951 GJ153321741 FUSE HOLDER
HF952 GJ153321741 FUSE HOLDER
R 951 GJ251273352201 CARBON RESISTOR 1/2W 3.3M 5% W
TB901 GJ727000010000 SOLDERRING LUG
(
TP0047341
TB902 GJ727000010000 SOLDERRING LUG
(
TP0047341
)
T951 GJ336660190013 POWER TRANS
A
EI66 AC120V 60
(Power supply board)
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 05
A
C 1 GJ270104763399 E. CAPACITOR
C 2 GJ116303891 CHIP CAPACITOR 0.1UFF
(
2012
)
25V
C 3 GJ116325191 CHIP CAPACITOR 100PF
(
2012
)
C 4 GJ116325191 CHIP CAPACITOR 100PF
(
2012
)
C 5 GJ116303891 CHIP CAPACITOR 0.1UFF
(
2012
)
25V
D 1 GJ374502042103 LED INFRARED LED SI
IC 1 GJ313060851302 IC IC UPD6134MC114
J 1 GJ121629691 CHIP RESISTOR OHM
Q
1 GJ312010941203 CHIP TRANSISTOR 2SD1781K
Q
R 1 GJ121780691 CHIP RESISTOR OHM
(
3216
)
5%
R 2 GJ121601191 CHIP RESISTOR OH
(
2012
)
1/10W
X 1 GJ362000020002 C.RESONATOR CERAMIC RESONAT
(Remote control board)
