1-2 (No.MB434)
SPECIFICATION
Design and specifications are subject to change without notice.
Amplifier Output Power 50 W per channel, min. RMS, driven into 6 Ω at 1kHz, with no
more than 10% total harmonic distortion. (IEC 268-3)
Input Sensitivity/Impedance
(1 kHz)
AUX IN 400 mV/50 kΩ
Speaker terminals 6 Ω - 16 Ω
Phones 32 Ω - 1 kΩ
15 mW/ch output into 32 Ω
Cassette Deck Section Frequency Response Type l (NORMAL) 63 Hz - 12 500 Hz
Wow And Flutter 0.15% (WRMS)
CD Player CD Capacity 3 CDs
Dynamic Range 83 dB
Signal-To-Noise Ratio 85 dB
Wow And Flutter Unmeasurable
Tuner FM Tuner : Tuning Range 87.5 MHz - 108.0 MHz(at AM10 kHz channel space)
87.50 MHz - 108.00 MHz(at AM9 kHz channel space)
AM Tuner : Tuning Range 530 kHz - 1710 kHz (at AM10 kHzchannel space)
531 kHz - 1710 kHz (at AM9 kHzchannel space)
Unit Dimensions 270 mm × 308 mm × 410 mm (W/H/D)
Mass Approx. 6.5 kg
Speaker Specifications
(each unit)
Type 2-way bass-reflex type
Speaker Unit Woofer : 13 cm cone × 1
Tweeter : 5 cm cone × 1
Power Handling Capacity 50 W
Impedance 6 Ω
Frequency Range 45 Hz - 22 000 Hz
Sound pressure level 87 dB/W
·m
Dimensions 205 mm × 308 mm × 209 mm (W/H/D)
Mass Approx. 2.9 kg
Power Specifications Power Requirements AC 110 V - 127 V/220 V - 240 V , adjustable with voltage se-
lector, 50 Hz/60 Hz
Power Consumption 110 W (power on mode)
13 W (in Standby mode)
1.2 W (in Eco mode)
To Next Page
