Front board
Block No. [0][2]
R566 BIRC6820105A00 C RESISTOR 6.8K
Ω
1/10W
R567 BIRC3320105A00 C RESISTOR 3.3K
Ω
1/10W
R568 BIRC1830105A00 C RESISTOR 18K
Ω
1/10W
R569 BIRC1830105A00 C RESISTOR 18K
Ω
1/10W
R570 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R571 BIRC5610045M00 C RESISTOR 560
Ω
1/4W
R572 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R573 BIRC3310045M00 C RESISTOR 330
Ω
1/4W
R574 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R575 BIRC1010085M00 C RESISTOR 100
Ω
1/8W J
R576 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R577 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R578 BIRC4710045M00 C RESISTOR 470
Ω
1/4W
R579 BIRC4700085M00 C RESISTOR 47
Ω
1/8W
R580 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R581 BIRC3320105A00 C RESISTOR 3.3K
Ω
1/10W
R701 BIRC0820105A00 C RESISTOR 8.2
Ω
1/10W
R702 BIRC8230105A00 C RESISTOR 82K
Ω
1/10W
R703 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R704 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R705 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R706 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R707 BIRC8230105A00 C RESISTOR 82K
Ω
1/10W
R708 BIRC4700105A00 C RESISTOR 47
Ω
1/10W
R709 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R710 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R711 BIRC8220105A00 C RESISTOR 8.2K
Ω
1/10W
R714 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R715 BIRC1830105A00 C RESISTOR 18K
Ω
1/10W
R716 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R717 BIRC1050105A00 C RESISTOR 1M
Ω
1/10W
R718 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R719 BIRC5620105A00 C RESISTOR 5.6K
Ω
1/10W
R720 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R721 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R722 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R723 BIRC6830105A00 C RESISTOR 68K
Ω
1/10W
R724 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R725 BIRC1530105A00 C RESISTOR 15K
Ω
1/10W
R726 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R727 BIRC8230105A00 C RESISTOR 82K
Ω
1/10W
R728 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R729 BIRC3940105A00 C RESISTOR 390K
Ω
1/10W
R730 BIRC1240105A00 C RESISTOR 120K
Ω
1/10W
R731 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R732 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R750 BIRC8200105A00 C RESISTOR 82
Ω
1/10W
R751 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R752 BIRC1330105A00 C RESISTOR 13K
Ω
1/10W
R753 BIRC1330105A00 C RESISTOR 13K
Ω
1/10W
R754 BIRC1330105A00 C RESISTOR 13K
Ω
1/10W
R755 BIRC1330105A00 C RESISTOR 13K
Ω
1/10W
R756 BIRC4720085M00 C RESISTOR 4.7K
Ω
1/8W J C
R757 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R758 BIRC1810105A00 C RESISTOR 180
Ω
1/10W
R759 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R760 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R761 BIRC6820105A00 C RESISTOR 6.8K
Ω
1/10W
R762 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R763 BIRC2020105A00 C RESISTOR 2K
Ω
1/10W
R764 BIRC0220025N00 C RESISTOR 2.2
Ω
1/2W J C
R780 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R781 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R782 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R801 BIRC1210105A00 C RESISTOR 120
Ω
1/10W
R802 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R803 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R804 BIRC1050105A00 C RESISTOR 1M
Ω
1/10W
R805 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R806 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R807 BIRC2210105A00 C RESISTOR 220
Ω
1/10W
R808 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R809 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R810 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R811 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R813 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R814 BIRC1210085M00 C RESISTOR 120
Ω
1/8W
R815 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
Symbol No.
Part No. Part Name Description Local
R816 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R817 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R821 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R850 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
L301 BI26100000KN00 FIXED INDUCTOR 10uH
L302 BI18A843556N00 FILTER BEAD 843556
L304 BI18A916121A00 FERRITE BEAD 120
Ω
L501 BI18A843556N00 FILTER BEAD 843556
L503 BI18A843556N00 FILTER BEAD 843556
L509 BI18A843556N00 FILTER BEAD 843556
L511 BI18A843556N00 FILTER BEAD 843556
L702 BI26100000KN00 FIXED INDUCTOR 10uH
L801 BI26100000KN00 FIXED INDUCTOR 10uH
L802 BI26100000KN00 FIXED INDUCTOR 10uH
L803 BI26100000KN00 FIXED INDUCTOR 10uH
L804 BI26100000KN00 FIXED INDUCTOR 10uH
L805 BI26100000KN00 FIXED INDUCTOR 10uH
L806 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
L808 BI18A843556N00 FILTER BEAD 843556
T401 BI603141V COIL OSC
CN201 BI12S1800061V CONNECTOR 18P
CN205 BI12S30039V CONNECTOR 3P
CN301 BI12S30039V CONNECTOR 3P
CN302 BI12S80024 CONNECTOR 8P
CN303 BI12S90024V FFC CONNECTOR 9P
CN306 BI12S120010 CONNECTOR 12P
CN601 BI12S240004V FFC CONNECTOR 24P
CN701 BI12S160031V FFC CONNECTOR 16P
CN702 BI12P60142V CONNECTOR WIRE 6P for CD MECH
CN703 BI12P100035V CONNECTOR WIRE 10P for CD MECH
JR301 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR401 BIRC0000085A00 C RESISTOR 0
Ω
1/8W
JR402 BIRC0000085A00 C RESISTOR 0
Ω
1/8W
JR403 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR404 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR405 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR406 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR409 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR701 BIRC0000085A00 C RESISTOR 0
Ω
1/8W
JR702 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR703 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR802 BIRC0000085A00 C RESISTOR 0
Ω
1/8W
JR803 BIRC0000085A00 C RESISTOR 0
Ω
1/8W
P1 BI11A050M0Y BLACK WIRE 50mm UL1007
P2 BI11AT233K0V BLACK WIRE WITH PLUG
X801 BI2102361 CRYSTAL 16.9344MHz
XT301 BI2101012 CRYSTAL 32.768KHz
XT302 BI29ZTA8.00P015 C RESONATOR 8MHz
Symbol No.
Part No. Part Name Description Local
IC1 PT6315 IC BI118301V
IC201 RPM7138-V4 IC BI115291
Q201 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q205 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
D201 1SS133 FR DIODE BI31SS133M000V7
D202 1SS133 FR DIODE BI31SS133M000V7
D206 1SS133 FR DIODE BI31SS133M000V7
D207 1SS133 FR DIODE BI31SS133M000V7
D208 1SS133 FR DIODE BI31SS133M000V7
D210 UZ5.1BSB Z DIODE BI3UZ5.1BSBM000
C201 BICC103500KA04 C CAPACITOR 0.01uF
C202 BICC103500KA04 C CAPACITOR 0.01uF
C203 BICE106500MP01 E CAPACTIOR 10uF 50V
C204 BICC102500KA04 C CAPACITOR 1000pF 50V
C205 BICE226500MP01 E CAPACITOR 22uF 50V
Symbol No.
Part No. Part Name Description Local
To Next Page
