28
Specifications
Amplifier
Output Power
155 W per channel, min. RMS, driven into 6 Ω at 1kHz, with
no more than 10% total harmonic distortion (IEC268-3)
Terminals
AUX IN
Input Sensitivity/Impedance(1 kHz) 400 mV/50 kΩ
Speaker terminals 6 Ω - 16 Ω
Phones 32 Ω - 1 kΩ
17 mW/ch output into 32 Ω
iPod
Compatible iPod types See page 13
Bus Power supply Max.5 V/500 mA
XM
Bus Power supply Max.5V-5.5V/500mA
CD Player
CD Capacity 3 CDs
Dynamic Range 85 dB
Signal-To-Noise Ratio 85 dB
Wow And Flutter Unmeasurable
Tuner
FM Tuner
Tuning Range 87.50 MHz - 108.00 MHz
AM Tuner
Tuning Range 522 kHz - 1 710 kHz
Unit
Dimensions 270 mm × 307 mm × 492mm (W/H/
D)
Mass Approx. 8.7 kg
Speaker Specifications (each unit)
SP-MXKC58
Type 3-way bass-reflex type
Speaker Unit Woofer: 16 cm cone × 1
Mid: 5 cm cone × 1
Tweeter: 2 cm dome × 1
Power Handling Capacity
160 W
Impedance 6 Ω
Frequency Range 45 Hz - 22 000 Hz
Sound pressure level 87 dB/W·m
Dimensions 220 mm × 324 mm × 238 mm(W/H/
D)
Mass Approx. 3.6 kg
Accessories
See page 4
Power Specifications
Power Requirements AC 110 V-127 V/220 V-240 V ,
adjustable with voltage selector,
50 Hz/60 Hz
Power Consumption 165 W (power on mode)
24 W (in Standby mode, with iPod
disconnected)
33 W (in Standby mode, with iPod
connected)
1 W (in ECO mode)
Design and specification are subject to change without notice.
