JVC MX-KC68J - Adjustment

1-20 (No.MB664<Rev.002>)
SECTION 4
ADJUSTMENT
4.1 Outline
4.2 How to go CD TEST MODE
4.3 Function specification
4.4 C1 error history
When 8 key is pressed, syscon send C1 err display command (0x9C 0x01 0x00).
If syscon receive C1 error display status (0xAA 0x01 0x00 ** **), it displays C1 error.
Syscon convert 2byte hex data to decimal data (00000-65635).
4.5 Special mode
CD TEST MODE
C1 error display
[SET] + [POWER] + AC in
Function
CD TEST MODE
C1 error display
C1 error display
Return to CD TEST MODE
Remocon
Remocon After receive data
Remocon
8
CANCEL
Key Operation FL display
CD TESTT
INITIAL
Er
*****
CD TESTT
[STOP] + [POWER] + [ 0 ] : COLD SET
[STOP] + [POWER] + [ 1 ] : FL DISPLAY turn on all segment
[STOP] + [POWER] + [10] :Micom version display (Mecha version, Destination, Syscon version)
Exsample In case of " 2501 JC241"
Mecha version: 25
ROM corr: 1
Destination: JC
Syscon version: 24
Syscon corr: 1
