MX-S6MD
1-7
Prior to performing the following procedure, remove
the top cover and the CD changer mechanism
assembly.
Disconnect the card wire from connectors CN511 on
the main board.
Remove the four screws I on both sides of the body.
Pull out the MD changer mechanism assembly from
behind upward while releasing the four joints d using
a screwdriver.
1.
2.
3.
Removing the MD changer mechanism
(See Fig.11 to 13 )
Prior to performing the following procedure, remove
the top cover.
Disconnect the card wire from connector CN801 on
the microcomputer board.
Remove the screw D attaching the microcomputer
board.
Disconnect the lower connector CN391, CN392 and
CN393 from the main board by pulling them.
1.
2.
3.
Removing the microcomputer board
(See Fig.14)
MD changer
mechanism assembly
CN511
Microcomputer board
CN801
CN393
CN392
CN391
Joints
d
I
I
D
Fig.11
Fig.12
Fig.13
Fig.14
MD changer
mechanism assembly
MD changer mechanism assembly
Joints d
